Disassembly and Reassembly _ 27

 Reassembly

Part Figure Description

Door-Lock S/W

1. Assembletheterminals.(2ea)

 MakesuretheWireharnessarenotgetting

stuckinotherparts.

2. AssembletheCoverDoorSwitchbygently

pushingtheredboxpartwithhand.

 MakesuretheWireharnessarenotgetting

stuckinotherparts.

3. Assemblethescrewswith(+)screwdriver.(2ea)

4. AssemblethewirediaphragmandFrameFront.

Ifthewirediaphragmislooseafterassembly

orisnotcorrectlyassembledatthecorrect

position(5o'clockor7o'clock),waterleakage

may occur.

 How to force open the locked Door

Part Figure Description

Door-Lock S/W

Beforeyoustart,disassembleCoverToprst

1. PutyourhandtopresstheDoor-LockSwitch.

(Thelocationyouneedtopressisshowninthe

picturewitharrow)
