15. Part List
No. Part Name Service Code Q'Ty Specification
1
PCB Complete 617 - 260 - 0239 1
2
SCR TPG TRS 4x16 411 - 007 - 5606 6
3
Control Plate 617 - 263 - 5347 1 202N
4
Stopping Pin 617 - 226 - 9603 1 RED COLOUR
5
M embrane Plate 617 - 259 - 8970 1 PET
6.1
Washer Lid Ass'y 617 - 259 - 8161 1
6.1.1
Washer Lid A SER - SPC - 0010 1 634N SILVER
6.1.2
Washer Lid B SER - SPC - 0012 1 634N SILVER
6.1.3
Lid Lens A 617 - 263 - 5392 1 293B BLUE
6.1.4
Lid Lens B 617 - 263 - 5385 1 293B BLUE
6.1.5
Hinge Shaft 617 - 259 - 8246 1
6.2
Lid Cushion 617 - 160 - 4252 2 TPE
6.3
Lid Spring 617 - 175 - 0935 1 SUS - 304 D1.0
6.4
Hinge Arm 617 - 221 - 7390 1 P.P TPC/ AR564
7
Hinge Shaft 617 - 250 - 0171 1 P.P POM
8
Hinge Spring 617 - 259 - 8253 1 SUS - 304 - WPA
9
Safety Lev er 617 - 259 - 8987 1 POM
10
Safety Lever Spring 617 - 175 - 0508 1
11
Switch 617 - 175 - 0485 1 KS - 12 -0
12
SCR TPG TRS 4x16 411 - 007 - 5606 1
13
Response Switch 617 - 235 - 7263 1 KPS - 59 -C
14
Lead Wire Ass'y 617 - 245 - 6621 1
15
Hose Band 617 - 148 - 4632 1
16
Magn etic Valve 617 - 242 - 2084 1 JWV - 203G
17
SCR TPG TRS 4x16 411 - 007 - 5606 3
18
SCR TPG TPS 4x16 411 - 007 - 5606 2
19
Pour Inlet Ass'y 617 - 245 - 4481 1
20
Air Trap Hose 617 - 259 - 8994 1
21
Hose Band 617 - 026 - 4921 2
22
Hose joint Ass y 617 - 259 - 9021 1
23
Pump Ass y 617 - 249 - 5514 1 ZH - 208G -2
24
Cushion 617 - 263 - 5101 2 T2.0 EPDM
25
Cover 617 - 259 - 9052 1 P.P - AR564
27
Feed Valve Fixture 617 - 244 - 6134 1 P.P
28
SCR TPG TRS 4x12 411 - 074 - 5806 2
