Peripheral Equipment Connections
Note: Because FAV CVBS and SVHS Y are connected parallelly, the picture may blend if the two peripherals
are used at the same time. Likewise, because SVHS C and SCART II R are connected parallelly, the picture
may blend if the two peripherals are used at the same time. Thus these two are not to be used at the same
time.
S-VHS Input
Video Input
Audio Inputss
Headphone
Audio Line Outss
Spdif Coaxial Output
Power Cord Input
Power On/Off Switch
HDMIInput2
HDMIInput1
For Service Use Only
SCART 2
SCART 1
Component Audio Inputss
Component Video Inputs (YBPbr)
RF
PCAudio Input
PCInput
CI Slot
AC~ 50 H z
POWER
