Sanyo DWM-1000 Service Manual

- 48 -
PARTS LIST
PRODUCT SAFETY NOTICE
EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE IEC
SYMBOL
!
!!
IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATED COMPONENTS IN WHICH SAFETY CAN BE OF
SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED BY
!
!!
, USE ONLY THE REPLACEMENT PARTS DESIGNATED,
OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT ARE DESIGNATED IN THE PARTS LIST
IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE MADE TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE PRODUCT TO THE CUSTOMER.
PACKING & ACCESSORIES
REF.NO. PART NO. DESCRIPTION
614 315 8875 CARTON CASE(1000)
614 317 9689 CARTON CASE(XE)
614 317 9696 CARTON CASE(UK)
614 318 0760 CARTON CASE(SS)
614 318 6366 CARTON CASE(KR)
614 317 3328 CARTON CASE(US)
614 318 3853 CARTON CASE(CA)
614 318 6373 CARTON CASE(AU)
614 278 9117 NOTICE(1000,US)
614 303 7484 LABEL,CAUTION,CUSHION TOP(1000)
614 315 9001 INSTRUCTION,MANUAL(1000)
614 317 9795 INSTRUCTION MANUAL(XE)
614 317 9818 INSTRUCTION MANUAL(UK)
614 318 0845 INSTRUCTION MANUAL(SS)
614 318 6434 INSTRUCTION MANUAL(KR)
614 317 3359 INSTRUCTION MANUAL(US)
614 318 3907 INSTRUCTION MANUAL(CA)
614 318 6441 INSTRUCTION MANUAL(AU)
614 317 9801 INSTRUCTION MANUAL,(GREEK)(XE)
614 317 3182 INSTRUCTION SHEET,QUICK GUIDE
(1000)
614 317 3366 INSTRUCTION,SHEET,QUICK GUIDE
(US)
614 315 8974 CUSHION,TOP
614 315 8981 CUSHION,BOTTOM
645 046 8278 POLY SHEET-1300X0500*NC,SET
(1000,UK,SS,KR,US,CA,AU)
645 047 3418 POLY SHEET-1300X0500*NC,SET(XE)
645 044 9413 REMOCON,RB-H520MT(1000,CA)
645 044 9420 REMOCON,RB-H5201ST(XE,UK,AU)
645 044 9437 REMOCON,RB-H5201(SS,KR)
645 046 8391 REMOCON,REM-H5201(US)
645 043 9735 BATTERY COVER,SERVICE PART
645 041 1373 CABLE,VIDEO,VIDEO-CABLE(1.5M)
645 047 0356 WIRE,MAIN SP
645 047 0363 WIRE,SUB WOOFER
645 017 2175 PLUG,ADAPTOR AC(SS)
or 645 006 4630 PLUG,ADAPTOR AC(SS)
CAUTION : Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4 W Carbon type and Chip type resistors.
Regular type capacitors are less than 50 V and less than 1000 µF type of Ceramic type, Electrical type and Chip type.
CABINET & CHASSIS
REF.NO. PART NO. DESCRIPTION
1 614 315 8516 ASSY,CABINET(1000,UK,SS,KR,AU)
1 614 317 9481 ASSY,CABINET(XE)
1 614 317 3236 ASSY,CABINET(US,CA)
1-1 614 319 0523 ASSY.BOX,SPEAKER
1-2 645 048 4957 LEFT SIDE COVER
1-3 645 048 4964 RIGHT SIDE COVER
1-4 645 048 4988 MID RANGE HOLDER
1-5 645 048 4971 RUBBER CATCHER
1-6 645 048 5015 MID RANGE
1-7 645 048 5084 JOIN WIRE
1-8 645 048 5138 SCREW,SIDE COVER
1-9 645 048 5121 SCREW,MID RANGE HOLDER
1-10 645 048 5091 SCREW,MID RANGE UNIT
FIXING PARTS
REF.NO. PART NO. DESCRIPTION
Y01 411 021 3503 SCR S-TPG BIN 3X10,
MOUNTING,PANEL
Y02 411 021 3503 SCR S-TPG BIN 3X10,FRONT PWB
Y03 645 046 8209 SCREW,HEAT SINK UNIT
Y04 645 046 8216 SCREW,PANEL FRONT SIDE
Y05 645 046 8261 SCREW,PANEL REAR
Y06 411 021 6405 SCR S-TPG BIN 3X8,
MPEG PWB-SHIELD MPEG
Y07 411 021 3503 SCR S-TPG BIN 3X10,MPEG UNIT
Y08 411 020 8905 SCR S-TPG BRZ+FLG 3X10,
DVD MECHA
REF.NO. PART NO. DESCRIPTION
1-11 645 048 5169 CUSHION,MID RANGE
2 614 315 8127 ASSY,GRILLE(1000,XE,UK,SS,KR,AU)
2 614 317 3250 ASSY,GRILLE(US)
2 614 318 3648 ASSY,GRILLE(CA)
3 614 315 6611 BUTTON(1000,XE,UK,SS,KR,AU)
3 614 317 3274 BUTTON(US,CA)
4 614 315 6727 MOUNTING,PANEL
5 614 315 8134 ASSY,PANEL,FRONT(1000,XE,UK,AU)
5 614 318 0708 ASSY,PANEL,FRONT(SS,KR)
5 614 317 3267 ASSY,PANEL,FRONT(US,CA)
6 614 315 6642 CHASSIS,MECHA/TRANS/PWB
7 614 315 6666 DEC,WINDOW,FL
8 614 315 7762 HOLDER,TRANS
9 614 315 6734 MOUNTING,PWB,JACK PWB FIX
10 614 310 3837 MOUNTING,FAN
11 614 315 6765 PANEL,REAR(1000)
11 614 317 5445 PANEL,REAR(XE)
11 614 317 5452 PANEL,REAR(UK)
11 614 317 5469 PANEL,REAR(SS)
11 614 318 6182 PANEL,REAR(KR)
11 614 317 3298 PANEL,REAR(US)
11 614 318 3679 PANEL,REAR(CA)
11 614 318 6199 PANEL.REAR(AU)
12 614 314 7107 SHIELD,MPEG PWB BOTTOM
13 614 314 7114 SHIELD,MPEG PWB TOP
14 614 315 6796 SHIELD,DVD MECHA,BOTTOM
15 614 315 6802 SHIELD,DVD MECHA,TOP
16 614 307 2638 LABEL,INDICATION,FUSE(1000)
17 614 315 8110 ASSY,DEC ESCUTCHEON
(1000,XE,UK,SS,KR,AU)
17 614 317 3243 ASSY,DEC,ESCUTCHEON(US,CA)
18 614 129 1901 FIXER,AC CORD
or 614 284 1884 FIXER,AC CORD
19 614 318 0166 SPACER,SHEET,CHASSIS
(1000,US,CA)
19 614 317 2994 SPACER,SHEET,CHASSIS
(XE,UK,SS,KR,AU)
20 614 129 9136 LUG,LEAD FIX
21 614 315 6628 BUTTON,SELECT(SS,KR)
22 614 317 5438 KNOB,ROTARY,MIC/ECHO VOL(SS,KR)
614 317 3090 LABEL,SAFETY(XE,UK,AU)
