Sanyo MDF-393 User Manual

Parts layout
Temperature display
Control panel
<Front view>
<In the chamber>
<Back side of control panel>
Power S
W
Battery SW
Temp. sensor
CO2 back-up discharge Filter AT sensor
Switch PCB
<Left side area> <Temp. control PCB>
Display PCB
Cover for Temp. control PCB
㪫㪼㫄㫇㪅㩷㪺㫆㫅㫋㫉㫆㫃㩷㪧㪚㪙
Battery
Power transformer
for PCB
25

Sanyo MDF-393 Specifications

General

Brand	Sanyo
Model	MDF-393
Category	Freezer
Language	English
