Cooling unit parts
<MDF-394/393(N)>
Item
Specifications
H side L side
Compressor
220V,60Hz
Type:C-1RN45L6A
Code:802 021 16
Type:CS200J1NS-7A
Code:7FB-0-M101-002-06
220V,50Hz
Type:C-1RN45L5A
Code:812 022 15
Type:CS200J1NS-4A
Code:7FB-0-M101-002-04
230/240V,50Hz
Type:C-1RN45L5A
Code:812 022 15
Type:KS200J1NS-4A1
Code:7FB-0-M101-002-05
Refrigerant oil
Ze-NIUSL22SA
Charged q’ty: 230cc
Ze-NIUSL22SA
Charged q’ty: 850cc
Cooling system
Forced air cooling㧔partially㧕
DSH
Forced air cooling㧔partially㧕
Oil cooler
Condenser
Type Fin and tube Cascade condenser
Condenser 12 columns x 3 lines P6.35mm
Fin 38pcs.
Coil pipeǾ6.35mm
Pre-condenser W 250mm
ʊ
ʊ
Frame pipe
Ǿ6.35mm
Evaporator
Type
Cascade condenser
Shell and tubeǾ80mm
Tube on sheet
Ǿ7.94mm
Capillary tube Ex. capillary
Resistance
PSI࡮kg/cm
2
94 PSI/G 0.363MPa 34 PSI/G
 Length 1800mm 3000mm 500mm
Outer diameter
Ǿ2.0mm Ǿ2.0mm Ǿ2.4mm
Inner diameter
Ǿ1.0mm (Ǿ0.9mm) Ǿ1.2mm
Refrigerant R-404A+4pt Charged q’ty: 331g R-508 Charged q’ty: 230g
Oil additive
n-Pentane
Charged-q’ty: 14g
n-Pentane
Charged q’ty: 33g
Dryer
4AXH-9 (For production in Dec.’08 or before)
Dry core (For production in Jan.’09 or later)
4AXH-9 Charged q’ty: 58g
Condensing fan
Ǿ230 mm 4 bladesޔ
Material: ABS Output:11W
Condensing fan
motor Type SE4-E11L5P
Oil separator
ʊ SPK-0S02S2
* Please use ‘Dry core’ for servicing.

5
