Sanyo MDF-U54VC User Manual

- 83 -
37
SPECIFICATIONS

Name Ultra-Low Temperature Freezer
Model MDF-U74V MDF-U74VC (For U.S.A. only)
External dimensions W1010 x D870 x H2010 (mm)
Internal dimensions W870 x D600 x H1400 (mm)
Effective capacity 728 L
Exterior Painted steel
Interior Painted steel
Outer door Painted steel
Inner door ABS resin panel with stainless frame, 2 doors
Shelf Stainless steel, 3 shelves (adjustable)
Inner dimension; W848 x D533 (mm), Load; 50 kg/shelf
Access port 17 mm diameter, 3 locations (back, bottom x 2)
Insulation Vacuum insulation panel + Rigid polyurethane foamed-in place
Compressor High stage side; Hermetic type, Output; 1100 W
Low stage side; Hermetic type, Output;1100 W
Evaporator Tube on sheet type
Condenser High stage side; Fin and tube type, Low stage side; Shell and tube type
Refrigerant High stage side; R-407D, Low stage side; R-508
Temperature controller Microcomputer control system
Temperature display Digital display
Thermal sensor Platinum resistance (Pt 1000ǡ)
Alarm High temp. alarm, Low temp. alarm, Power failure alarm
Door alarm, Filter alarm
Remote alarm contact Allowable contact capacity: 30 VDC, 2 A
Battery Nickel-metal-hydride battery, 6 VDC, 1100 mAh, Auto-recharge (5HR-AAC)
Accessories 1 set of key, 1 scraper
Weight 346 kg 351 kg
Voltage booster None Built-in
Optional component Inventory rack (IR-220U, IR-224U), Independent inner door (MDF-7ID),
Automatic temperature recorder (MTR-G85)*,
Interface board (MTR-480), LAN interface board (MTR-L03),
Data acquisition system (MTR-5000),
Back-up system (CVK-UB2, CVK-UB2(I)): LCO
2,
(CVK-UBN2): LN
2
Note:
• Design or specifications will be subject to change without notice.
• The battery for power failure alarm is an article for consumption. It is recommended that the
battery will be replaced about every 3 years. Contact Sanyo sales representative or agent at the
time of replacement of the battery for recycling.
• Fan motors are expendable supplies. Replace them for about every 6 years. Contact Sanyo
sales representative or agent at the time of replacement of the fan motor.
*: Power source of the automatic temperature recorder shall be 220 V.
