Sanyo PLC-SW20A User Manual

-17-
■ Power Source List of IC
Type Volt Pin No. Location
(Main Unit)
AL 5V 1 IC4801
14 IC4802
5 IC4803
24 IC3801
16 IC3871
1 IC3841
5IC871
5IC881
5IC891
4 IC1821
AL 3.3V 1 IC1821
24,25 IC9801
4,16 IC1301
5 IC1302
2 IC1303
8 IC1304
20 IC1351
20 IC1352
1IC311
8IC312
14 IC341
8IC351
37,47 IC801
11,33 IC811
5 IC1801
8 IC1802
20 IC1803
20 IC1804
20 IC1805
20 IC1806
20 IC1822
20 IC1823
8 IC1825
5 IC1826
IC301
AL 2.5V IC301
Type Volt Pin No. Location
(Main Unit)
AL 2.5V IC6101
AL3 3.3V IC6101
5 IC6102
2 IC6151
AL2 3.3V 8 IC1824
14 IC251
8 IC7208
8 IC7209
8 IC7210
AL5 3.3V IC201
VD 5V IC5101
DIG 3.3V IC5101
AUD 5V 1IC001
8IC002
9V 16 IC5001
ANLG 5V/-5 5 / 2 IC7201
5 / 2 IC7202
5 / 2 IC7204
15 / 13 IC7202
5 / 2 IC8201
5 / 2 IC8202
5 / 2 IC8203
ANLG 5V 13 IC7101
14 IC7203
14 IC7206
(Sub Unit)
SYNC 5V 13 IC7271
16 IC7272
SWD 3.3V IC401
SWD 2.5V IC401
SWD 15.5V/5V IC501
IC531
IC561
SYNC 5V 13 IC7271
16 IC7272
