Sanyo PLC-SW20A User Manual

Electrical Parts List
-34-
R516 401 105 2607 MT-GLAZE 22 JA 1/16W
R518 401 105 2607 MT-GLAZE 22 JA 1/16W
R531 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R532 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R535 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R539 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R541 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R542 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R544 401 105 0603 MT-GLAZE 10K JA 1/16W
R545 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R546 401 105 2607 MT-GLAZE 22 JA 1/16W
R548 401 105 2607 MT-GLAZE 22 JA 1/16W
R561 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R562 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R565 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R569 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R571 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R572 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R574 401 105 0603 MT-GLAZE 10K JA 1/16W
R575 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R576 401 105 2607 MT-GLAZE 22 JA 1/16W
R578 401 105 2607 MT-GLAZE 22 JA 1/16W
R7271 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R7272 401 105 4205 MT-GLAZE 33K JA 1/16W
R7273 401 105 5400 MT-GLAZE 47K JA 1/16W
R7274 401 105 0504 MT-GLAZE 1K JA 1/16W
R7275 401 105 0504 MT-GLAZE 1K JA 1/16W
R7276 401 105 1709 MT-GLAZE 150K JA 1/16W
R7277 401 177 2109 MT-GLAZE 4.7M JA 1/16W
R7278 401 105 4601 MT-GLAZE 3.9K JA 1/16W
R7279 401 105 7305 MT-GLAZE 820 JA 1/16W
R7280 401 105 0504 MT-GLAZE 1K JA 1/16W
R7281 401 105 0504 MT-GLAZE 1K JA 1/16W
R7282 401 105 5400 MT-GLAZE 47K JA 1/16W
R7283 401 105 2102 MT-GLAZE 18K JA 1/16W
R7284 401 105 0603 MT-GLAZE 10K JA 1/16W
R7285 401 105 0504 MT-GLAZE 1K JA 1/16W
R7286 401 105 0504 MT-GLAZE 1K JA 1/16W
R7287 401 105 0504 MT-GLAZE 1K JA 1/16W
R7288 401 105 0504 MT-GLAZE 1K JA 1/16W
R7289 401 105 2805 MT-GLAZE 2.2K JA 1/16W
R7290 401 105 4106 MT-GLAZE 3.3K JA 1/16W
R7291 401 105 2805 MT-GLAZE 2.2K JA 1/16W
R7292 401 105 4106 MT-GLAZE 3.3K JA 1/16W
R7293 401 105 2805 MT-GLAZE 2.2K JA 1/16W
R7294 401 105 4106 MT-GLAZE 3.3K JA 1/16W
COIL
L1401 645 020 1776 INDUCTOR,3.3U M
L1451 645 020 1776 INDUCTOR,3.3U M
L2501 401 036 8907 MT-GLAZE 5.6 JA 1/8W
L2502 401 036 8907 MT-GLAZE 5.6 JA 1/8W
L3561 645 026 1008 INDUCTOR,3.3U M
L501 645 002 5129 INDUCTOR,0.47U M
L502 645 002 5129 INDUCTOR,0.47U M
L503 645 020 1776 INDUCTOR,3.3U M
L531 645 002 5129 INDUCTOR,0.47U M
L532 645 002 5129 INDUCTOR,0.47U M
L533 645 020 1776 INDUCTOR,3.3U M
L561 645 002 5129 INDUCTOR,0.47U M
L562 645 002 5129 INDUCTOR,0.47U M
L563 645 020 1776 INDUCTOR,3.3U M
DIODE
D2502 407 149 0807 DIODE 1SS355-TE-17
D2503 407 149 0807 DIODE 1SS355-TE-17
D2601 407 208 9703 ZD UDZS-TE-175.6B
D2611 407 149 0807 DIODE 1SS355-TE-17
D2621 407 149 0807 DIODE 1SS355-TE-17
MISCELLANEOUS
X7271 645 035 8838 OSC,CERAMIC 500.0KHZ
610 300 2521 ASSY,PWB,R/C MS8A 1AA0B10C398AC
CAPACITOR
C2801 403 283 6309 CERAMIC 1U Z 10V
C2802 403 157 6602 CERAMIC 470P K 50V
RESISTOR
R2801 401 105 5103 MT-GLAZE 47 JA 1/16W
R2802 401 105 0405 MT-GLAZE 100 JA 1/16W
MISCELLANEOUS
A2801 645 044 8157 UNIT,REMOCON RECEIVER
Key No. Part No. Description Key No. Part No. Description
