6
2-3. Other Component Specifications
Indoor Unit SAP–KM97GHS5A SAP–KM97GHS5A/E
Transformer (TR) ATR-J125
Rating Primary AC 230V, 50Hz
Secondary 19V, 0.631A
Capacity 12VA
Coil resistance Ω (at 21°C) Primary (WHT – WHT): 205 ± 10%
Secondary (BRN – BRN): 1.5 ± 10%
Thermal cut-off temp. 150°C
Thermistor (Coil sensor TH1) PBC-41E-S4
Resistance kΩ –20°C 40.1 ± 5% 20°C 6.5 ± 5%
–10°C 24.4 ± 5% 30°C 4.4 ± 5%
0°C 15.3 ± 5% 40°C 3.0 ± 5%
10°C 9.9 ± 5% 50°C 2.1 ± 5%
Thermistor (Room sensor TH2) DTN-TKS106E
Resistance kΩ 25°C 5.0 ± 3%
Outdoor Unit SAP–MC1827GH5
Power Relay (PRA, PRB) DFU24D1-F (M)
Coil rating DC 24V
Coil resistance Ω (at 20°C) 650 ± 10%
Contact rating AC 250V, 20A
Termistor (Coil sensor) PBC-41E-S15
Resistance kΩ –10°C 23.7 ± 5% 25°C 5.3 ± 5%
0°C 15.0 ± 5% 30°C 4.4 ± 5%
10°C 9.7 ± 5% 40°C 3.1 ± 5%
20°C 6.5 ± 5%
Solenoid Coil (4-way Valve SCA, SCB) CHV-01Ai038A1 (Coil), CHV-0101 (Valve)
Coil rating AC 230V, 50Hz, 5W
Coil resistance Ω (at 20°C) 1,408 ± 7%
