2. SPECIFICATIONS
2-1. Unit Specifications
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Remarks: Rating conditions are:
Cooling: Indoor air temperature 27°C DB/19°C WB
Outdoor air temperature 35°C DB/24°C WB
Heating: Indoor air temperature 20°C DB
Outdoor air temperature 7°C DB/6°C WB
2
No. of indoor units. 1-unit
Power Source 220 – 240 V ~ 50 Hz
Cooling Heating
Capacity
kW 2.60 / 2.60 / 2.65 3.25 / 3.25 / 3.30
BTU/h 8,900 / 8,900 / 9,000 11,100 / 11,100 / 11,300
Air circulation (High) m
3
/h 450
Moisture removal (High) Liters/h 1.1 —
Voltage rating V 220 / 230 / 240
Available voltage range V 198 to 264
Running amperes A 4.6 / 4.6 / 4.6 5.1 / 5.0 / 4.9
Power input W 990 / 1,010 / 1,040 1,090 / 1,090 / 1,090
Power factor % 98 / 95 / 94 97 / 95 / 93
C.O.P. W/W 2.6 / 2.6 / 2.5 3.0 / 3.0 / 3.0
Compressor locked rotor amperes A 23 / 24 / 25
Controls / Temperature control Microprocessor / I.C. thermostat
Control unit Wireless remote control unit
Timer 1-hour OFF / 12-hour ON or OFF
Fan speeds Indoor / Outdoor 3 and Auto / 1
Airflow direction (Indoor)
Horizontal Manual
Vertical Auto
Air filter Washable, Anti–Mold
Compressor Rotary (Hermetic)
Refrigerant / Amount charged at shipment g R22 / 1,200
Refrigerant control Capillary tube
Operation sound
Indoor – Hi / Me / Lo dB-A 40 / 34 / 31
Outdoor – Hi dB-A 53
Refrigerant tubing connections Flare type
Max. allowable tubing length at shipment m 7.5
Refrigerant tube
Narrow tube mm (in.) 6.35 (1/4)
diameter
Wide tube mm (in.) 9.52 (3/8)
Refrigerant tube kit / Accessories Optional / Hanging wall bracket
Indoor Unit Outdoor Unit
Unit dimensions Height mm 265 630
Width mm 805 830
Depth mm 145 305
package dimensions Height mm 208 713
Width mm 855 994
Depth mm 326 413
Weight
Net kg 7.5 61.0
Shipping kg 10.0 66.0
Shipping volume m
3
0.06 0.29
Dimensions & Weight Features Electrical Rating Performance
Indoor Unit SAP–KM97GHS5A or SAP–KM97GHS5A /E
Outdoor Unit SAP–MC1827GH5
