Scheppach Precisa 3.0 User Manual

18 deutsch
Manufacturer
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear customer, We wish you much pleasure and success
withyournewScheppachmachine.
Note
Inaccordancewithvalidproductliabilitylaws,themanu-
facturer of this device shall not be responsible for damage
toandfromthisdevicewhichresultsfrom:
• Impropercare.
• NoncompliancewiththeOperatingInstructions.
• Repairsmadebyunauthorizedpersons.
• Theinstallationanduseofanypartswhicharenotorigi-
nal Scheppach replacement parts.
• Improperuseandapplication.
• Failure the electrical system as aresult of noncompli-
ancewith thelegal andapplicable electricaldirectives
andVDEregulations0100,DIN57113/VDE0113.
We recommend
that you read through the entire operating instructions be-
fore putting into operation.
These operating instructions are to assist you in getting to
knowyourmachineandutilizeitsproperapplications.
Theoperatinginstructionscontainimportantnotesonhow
youworkwiththemachinesafely,expertly,andeconomi-
cally, and howyou can avoid hazards, save repair costs,
reduce downtime and increase thereliability and service
life of the machine.
Inadditiontothesafetyrequirementscontainedinthese
operating instructions, you must be careful to observe your
country’s applicable regulations.
The operating instructions must always be near the ma-
chine.Puttheminaplasticfoldertoprotectthemfromdirt
and humidity. They must be read by every operator before
beginningworkandobservedconscientiously.Onlypersons
whohavebeentrainedintheuseofthemachineandhave
beeninformed of the various dangersmaywork with the
machine.Therequiredminimumagemustbeobserved.
Inadditiontothesafetyrequirementscontainedinthese
operating instructions and your country’s applicable regula-
tions, you should observe the generally recognized technical
rulesconcerningtheoperationofwoodworkingmachines.
General notes
• Afterunpacking,checkallpartsforanytransportdam-
age. Inform the supplier immediately of any faults.
• Latercomplaintscannotbeconsidered.
• Makesurethedeliveryiscomplete.
• Before putting into operation, familiarize yourself with
the machine by carefully reading these instructions.
• UseonlyoriginalScheppachaccessories,wearingorre-
placement parts. You can find replacement parts at your
Scheppach dealer.
• Whenordering,includeouritemnumberandthetypeand
year of construction of the machine.
Precisa 3.0
Entendue de livraison
CircularsawbenchPrecisa3.0-partlyassembled
Sawbladø280
Long fence
Crosscut / mitre gauge
Rivingknife
Dust extractor
Suction connection piece
Push-stick
Push-grip
Holding mandre
Assemblytoo
Operating instructions
Technical data
Dimensions: Length/Width/Heigth mm
1000x700x1100
Total length with table exrension mm
1640
Table size mm
800x570
Table heigth mm
850
Ø circular saw blade mm
280
Blade tilt °
from 90° to 45°
Cut heigth 90° mm
from 0 to 90
Cut heigth 45° mm
from 0 to 65
Rotation speed 1/min
4100
Cutting speed m/s
50
Longueur de guide parallèle mm
800
Cutting width between blade and
parallel guide mm
260
Cutting width between blade and
parallel guide (with extenseion table) mm
890
Angling fence
-45° to 0 to +45°
Angling fence guide
T-Prole
Length extension table
supplied standard
Length extension table dimensions mm
530x600
Table length included length
extension table mm
1440
Suction connection Ø mm
50
Machine sustion connection Ø mm
100
Nett weight kg
~160
Drive
Electric motor V/Hz
240/50 400/50
Input power P1 kW
2,6 3,2
Output power P2 kW
2,0 2,6
Motor rotary speed 1/min
2800 2800
Drive type
S6/40% S6/40%
Subjecttotechnicalmodications!
Noise characteristic values
Measurement conditions in accordance with draft pr EN
1870-1:1995-07
The values stated are emission values and are therefore
notnecessarilysafeoperatingvalues.Althoughthereisa
correlation between emission and immission levels, you
cannotreliablydeducefromthiswhetheradditionalsafety
measuresarerequiredornot.Factorswhichcaninuence
theimmissionlevelcurrentlyattheworkstationcomprise
thedurationoftheeffects,thecharacteristicsofthework
room, other sources of noise etc., for example, the number of
machines and adjacent operations. The permissible values
perworkstationcanalsovaryfromcountrytocountry.This
information should nevertheless enable the user to make a
better estimation of dangers and risks.
