7
21LT-45S
REF No. PARTS DESCRIPTION SN CODE EX CODE
. 30002749 21" CPT TUBE SAFE BQ CG
. 30028645 21" DEG COIL&EARTH CB. SAFE WO/UL SHARP AG AS
TUNER
TU201 30009637 TUNER WSP (PLL) 38.9 MK2 - BATCH AR BC
INTEGRATED CIRCUITS
IC101 30018063 IC HT48RA0A OTP AF AR
IC118 30001506 IC TL431 AC AH
IC401 30013986 IC AAMP TDA7266L 5W SIP10 AD AM
IC403 30026922 IC STV2248H (SHRINK56) AR BC
IC502 30001669 PREAMPLIFIER TFMS1380 AD AM
IC600 30015306 IC TDA8174AW AD AN
IC800 30011968 IC SMPS MC44608 DIP8 AF AQ
IC801 30015087 IC SAFE OPTOCOUPLER TCET1102G AA AE
IC803 30001500 IC LM7808 AC AH
IC804 30001622 IC 7805 (1A) AB AF
IC806 30014346 IC 78L05 TO-92 (100mA) AA AE
TRANSISTORS
Q100 30001453 TR BC337 AA AC
Q601 30013656 TR POWER STX112-AP AA AE
Q804 30001454 TR BC548B AA AC
DIODES
D100 30002733 LED INFRARED IR333 AA AC
D106 30001377 DIODE ZENER 33V UZT 33B AB AF
D407 30001284 DIODE 1N4148 0.15A/100V 0.5A AA AB
D505 30001284 DIODE 1N4148 0.15A/100V 0.5A AA AB
D506 30001284 DIODE 1N4148 0.15A/100V 0.5A AA AB
D509 30001279 LED RED/GREEN LTL293SJ AC AH
D602 30001329 DIODE 1N4007 1A/1000V 30A AA AB
D608 30001318 DIODE BA159 1A/800V 20A AA AB
D609 30001318 DIODE BA159 1A/800V 20A AA AB
D610 30001318 DIODE BA159 1A/800V 20A AA AB
D614 30001318 DIODE BA159 1A/800V 20A AA AB
D800 30001318 DIODE BA159 1A/800V 20A AA AB
D801 30001347 DIODE ZENER 8.2V AA AB
D802 30001318 DIODE BA159 1A/800V 20A AA AB
D803 30001315 DIODE BYD33D 1A/200V 20A AA AE
D804 30001318 DIODE BA159 1A/800V 20A AA AB
D805 30001315 DIODE BYD33D 1A/200V 20A AA AE
D806 30001315 DIODE BYD33D 1A/200V 20A AA AE
D808 30007681 DIODE UF5407 3A/800V 150A AB AF
D809 30001329 DIODE 1N4007 1A/1000V 30A AA AB
D811 30001329 DIODE 1N4007 1A/1000V 30A AA AB
D813 30001329 DIODE 1N4007 1A/1000V 30A AA AB
D837 30001329 DIODE 1N4007 1A/1000V 30A AA AB
D838 30001329 DIODE 1N4007 1A/1000V 30A AA AB
D889 30001384 TR MCR22-6 AB AG
D890 30001329 DIODE 1N4007 1A/1000V 30A AA AB
D893 30001318 DIODE BA159 1A/800V 20A AA AB
D894 30001318 DIODE BA159 1A/800V 20A AA AB
D900 30001318 DIODE BA159 1A/800V 20A AA AB
D901 30001318 DIODE BA159 1A/800V 20A AA AB
D902 30001318 DIODE BA159 1A/800V 20A AA AB
D903 30001344 DIODE ZENER 6.2V 1/2W AA AB
D904 30001349 DIODE ZENER 11V AA AB
D905 30001349 DIODE ZENER 11V AA AB
D906 30001349 DIODE ZENER 11V AA AB
PACKAGED CIRCUITS
X100 30002852 XTAL REZ 455KHZ AA AD
X401 30001749 XTAL 4.433619 MHZ (AK15) AC AK
X402 30015592 XTAL 3.579545 (WO/LOAD CAP) AB AG
X403 30000074 CAP MKT 100NF 63V J AA AC
X501 30002851 XTAL 4MHZ L.C=30PF AC AH
COILS
L101 30013412 FERRITE BEAD (0805) MMZ2012Y152B AA AA
L110 30013412 FERRITE BEAD (0805) MMZ2012Y152B AA AA
L111 30013412 FERRITE BEAD (0805) MMZ2012Y152B AA AA
PICTURE TUBE
!
!
!
REF No. PARTS DESCRIPTION SN CODE EX CODE
L112 30013412 FERRITE BEAD (0805) MMZ2012Y152B AA AA
L113 30013412 FERRITE BEAD (0805) MMZ2012Y152B AA AA
L114 30013412 FERRITE BEAD (0805) MMZ2012Y152B AA AA
L201 30001979 FIXED COIL 1UH Q45 M-A AA AB
L210 30001971 FERRITE BEAT (805) BLM21A601S AA AD
L211 30001971 FERRITE BEAT (805) BLM21A601S AA AD
L401 30001971 FERRITE BEAT (805) BLM21A601S AA AD
L402 30001992 FIXED COIL 10UH Q65 K-A AA AB
L403 30001971 FERRITE BEAT (805) BLM21A601S AA AD
L404 30001990 . AA AB
L406 30001971 FERRITE BEAT (805) BLM21A601S AA AD
L407 30002002 FIXED COIL 47UH Q60 K AA AB
L601 30001990 FIXED COIL 6.8UH Q75 K AA AB
L603 30002149 LINEARITY COIL 50UH (06-06A) AE AN
L802 30001971 FERRITE BEAT (805) BLM21A601S AA AD
L803 30001984 FIXED COIL 2.2UH Q55 M-AX AA AB
L805 30001971 FERRITE BEAT (805) BLM21A601S AA AD
L806 30001971 FERRITE BEAT (805) BLM21A601S AA AD
L807 30001992 AA AB
CERAMIC FILTERS
Z401 30001707 FILTER SAW L9453M AH AU
Z402 30001690 FILTER SAW K2962M AH AU
Z403 30001728 TRIPLE TRAP TPT02B AG AT
Z404 30001724 FILTER SER TRAP TPS 5.5MHZ AB AF
TRANSFORMERS
TR601 30017788 TRF FBT SAFE 90ø (AK30,AK36 LAYER TYPE) AT BE
TR801 30002100 LINE FILTER SAFE 2*27MH AC AH
TR802 30027706 TRF SMPS AK44 90° (170-270V) Audio=12V AF AQ
CAPACITORS
C100 30000352 CAP EL 100UF 16V M AA AB
C108 30000371 CAP EL 22UF 50V M AA AB
C201 30000400 CAP EL 47UF 50V M AA AB
C205 30000371 CAP EL 22UF 50V M AA AB
C300 30000400 CAP EL 47UF 50V M AA AB
C302 30000092 CAP MKT 220NF 63V J AA AD
C404 30000225 CAP CER 220PF 50V J SL AA AB
C409 30000345 CAP EL 10UF 50V M AA AB
C410 30000384 CAP EL 2.2UF 50V M AA AB
C411 30000345 CAP EL 10UF 50V M AA AB
C413 30000362 CAP EL 1UF 50V M AA AB
C416 30000362 CAP EL 1UF 50V M AA AB
C417 30000362 CAP EL 1UF 50V M AA AB
C419 30000413 CAP EL 4.7UF 50V M AA AB
C420 30000100 CAP MKT 330NF 63V J AA AD
C422 30000400 CAP EL 47UF 50V M AA AB
C423 30000400 CAP EL 47UF 50V M AA AB
C424 30000345 CAP EL 10UF 50V M AA AB
C431 30000362 CAP EL 1UF 50V M AA AB
C433 30000345 CAP EL 10UF 50V M AA AB
C436 30000109 CAP MKT 470NF 63V J AA AD
C440 30000074 CAP MKT 100NF 63V J AA AC
C443 30000362 CAP EL 1UF 50V M AA AB
C444 30000384 CAP EL 2.2UF 50V M AA AB
C446 30000345 CAP EL 10UF 50V M AA AB
C460 30000345 CAP EL 10UF 50V M AA AB
C502 30000396 CAP EL 47UF 16V M AA AB
C513 30000371 CAP EL 22UF 50V M AA AB
C519 30000352 CAP EL 100UF 16V M AA AB
C531 30000384 CAP EL 2.2UF 50V M AA AB
C536 30000074 CAP MKT 100NF 63V J AA AC
C541 30000109 CAP MKT 470NF 63V J AA AD
C542 30000205 CAP CER 150PF 50V J SL AA AB
C543 30000205 CAP CER 150PF 50V J SL AA AB
C603 30000384 CAP EL 2.2UF 50V M AA AB
C604 30000345 CAP EL 10UF 50V M AA AB
C608 30000107 CAP MKT 47NF 250V J AA AD
C610 30000355 CAP EL 100UF 50V M AA AB
C611 30000092 CAP MKT 220NF 63V J AA AD
C613 30000078 CAP MKT 1UF 100V M AB AF
C615 30000359 CAP EL 1000UF 16V M AA AC
C616 30000352 CAP EL 100UF 16V M AA AB
C618 30007100 CAP MKP SAFE 10NF 1600V %3.5 AA AE
C619 30000131 CAP MKP SAFE 100NF 250V J AA AB
C624 30000350 CAP EL 10UF 250V M AA AD
C627 30000154 CAP MKP SAFE 390NF 250V J AB AG
C628 30018380 CAP EL 3.3UF 160V M 105° AA AB
C631 30000410 CAP EL 470UF 50V M AB AF
C632 30000100 CAP MKT 330NF 63V J AA AD
C633 30016085 CAP EL 10UF 63V 105° AA AB
C634 30000409 CAP EL 470UF 25V M AA AD
C635 30000100 CAP MKT 330NF 63V J AA AD
C636 30000387 CAP EL 33UF 50V M AA AB
C641 30000345 CAP EL 10UF 50V M AA AB
C643 30000116 CAP MKT 68NF 63V J AA AC
C644 30000362 CAP EL 1UF 50V M AA AB
C645 30000352 CAP EL 100UF 16V M AA AB
C801 30000094 CAP MKT SAFE 220NF 275V M AC AA AB
C802 30000094 CAP MKT SAFE 220NF 275V M AC AA AB
C803 30000433 CAP CER 1NF 1KV M B AA AB
C805 30018085 CAP VAR SAFE 510V K MFCN14D511 AA AD
C806 30000433 CAP CER 1NF 1KV M B AA AB
C808 30000295 CAP CER 100NF 50V Z F AA AB
C809 30000420 CAP EL 150UF 400V M AF AQ
!
!
!
!
!
!
!
21LT-45S PARTS LISTING
REPLACEMENT PARTS
Replacement parts which have special safety characteristics are identified in
this manual. Electrical components having such features are identified by
in the Replacement Parts Listing.
The use of a substitute replacement part which does not have the same safety
characteristics as the factory recommended is not permitted.
Replacement parts not shown in this service manual may create shock fire, or
other hazards.
HOW TO ORDER REPLACEMENT PARTS
To have your order completed promptly and correctly please supply the follow-
ing information.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. (*) 4. DESCRIPTION
5. CODE 6. QUANTITY
(*) When ordering any part, a “V” should be added before the Part No.
(*)
