Turning the TV on/off
Turning on/off the power
•To turn on the power
Press POWER on the TV or remote control. (After a few
seconds, an image appears with sound.)
•To turn off the power
Switch it off by pressing POWER on the TV or remote
control.
NOTE
•If you are not going to use this TV for a long period of time,
be sure to remove the AC cord from the AC outlet.
•Minor power is consumed when the unit is in standby
mode.
Easy setup
When the TV powers on for the first time after
purchase, the initial auto installation wizard appears.
Follow the menu and make the necessary settings
one after another.
1
Press POWER on the remote control.
•Theinitialautoinstallationwizardappears.
Press ENTER to start the wizard.
2
Press
a
/
b
to select the desired language, and
then press ENTER.
Press
a
/
b
to select your country channels in
“Location”, and then press ENTER.
Press
c
/
d
to select “HOME” or “Store”, and
then press ENTER.
HOME:
•“STANDARD”willbethedefaultvalueforthe
“AV mode” setting.
Store:
•“DYNAMIC(Fixed)”willbethedefaultvalue
for the “AV mode” setting. If the “AV mode” is
changed, the TV will automatically switch back to
“DYNAMIC(Fixed)”whenthereisnofurtherchange
to TV setting for 30 minutes.
•TochangetheStoremodetoHOMEmode,please
refer to page 16 to reset the unit.
3
Press
a
/
b
to select “DTV”, “ATV” or
“DTV + ATV” in “Search type”, and then press
ENTER.
•Autoinstallationwillbeexecuted.
•Youdonotneedtodoanythingduringtheauto
search.
•Ifyouselect“Others”country,someofDTVchannel
may not tune properly.
Press
c
/
d
to select “Start” or “Cancel”, and
then press ENTER for searching receivable
channels.
NOTE
•In the setting of some country, selecting of “DTV”, “ATV”
or “DTV + ATV” may not be shown.
•A region or service selection screen may display depending
on the country settings or cable providers selections.
Follow the screen prompts to make the selections.
Digital setting
YoucanrecongureDTVservicessettings
automatically or manually.
1
Press MENU and the MENU screen displays.
2
Press
c
/
d
to select “Initial setup”.
3
Press
a
/
b
to select “Digital setting”, and
then press ENTER. If you have already set the
password, enter it here.
•See“Childlock”tosetpassword.
4
Press
a
/
b
to select the desired menu item,
and then press ENTER.
H
Auto search
Use this menu to add new services automatically
after auto installation has been completed.
•Press
a
/
b
to select “DTV” or “DTV+ATV”.
H
Manual search
Add new services within a specified channel band.
•Press
c
/
d
to find the channel and then press ENTER.
H
Signal information
Use this menu to check signal information depends
on receiving channel.
Part names (Continued)
TV (Rear)
LC-40SA5200X
7
INPUT 3
R - AUDIO - L
VIDEO
1
3
4
5
2
OUT (L/R)
AUDIO
SERVICE
ONLY
ANT
ARC
HDMI 2
6
8
HDMI 1
USB
(DC5V 1.5A)
1 /AUDIO OUT (L/R) terminal
2 SERVICEONLYterminal**
3 Antenna input terminal
4 USBterminal*
5 INPUT 2 (HDMI) terminal
6 INPUT 1 (HDMI/ARC) terminal
7 INPUT 3 terminals
8 One Button Key
One Button Key Functions Descriptions
Single Press On/Off (No OSD display)
Long Press Sub-menu display on TV screen
(10s timeout)
Function During
Menu
1.INPUT*
2. CH
r
*
3. CH
s
*
4.VOL+*
5.VOL–*
*SinglePress:ScrollDown
*HoldPress:SelectItem
LC-50SA5200X
1
3
4
5
2
7
12
8
9
10
11
OUT (L/R)
AUDIO
SERVICE
ONLY
ANT
ARC
INPUT 3
R - AUDIO - L
VIDEO
HDMI 2
6
HDMI 1
USB
(DC5V 1.5A)
1 /AUDIO OUT (L/R) terminal
2 SERVICEONLYterminal**
3 Antenna input terminal
4 USBterminal*
5 INPUT 2 (HDMI) terminal
6 INPUT 1 (HDMI/ARC) terminal
7 POWER (On/Off) button
8 MENU button
9 INPUT button
10 Channel up (
r
)/down (
s
) buttons
11 Volume up (
e
)/down (
f
) buttons
12 INPUT 3 terminals
* USBterminaluseforUSBmediaplayer.(Seepage26.)
** Usuallydonotconnectanythingtothisterminalasitreservedonlyforservicepersonnel.
•The illustrations and on-screen displays in this operation manual are for explanation purposes and may vary slightly from
the actual operations.
•Some features differ depending on the selected country.
LC-40_50SA5200X_G870_EN.indd 6 1/15/2018 2:06:35 PM

Sharp AQUOS LC-40SA5200X Specifications

General

Brand	Sharp
Model	AQUOS LC-40SA5200X
Category	LED TV
Language	English
