NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PART CODE
PRICE
RANK
DESCRIPTION
CD-C470H,C470E,C480H/CP-C470H,C470E,C480H
SPEAKER BOX PARTS
701 92L121-0085 J AS Net Frame Ass’y
[CD-C470H/470E]
701 92L121-0096 J Net Frame Ass’y [CD-C480H]
702 92L351-0147 J AB Label [CD-C470H/470E]
702 92L351-0166 J Label [CD-C480H]
703 92L128-0003 J Bottom Cabinet
704 92L372-0082 J AB Screw,ø3×20mm
705 92L291-0035 J AE Speaker Cord
706 92L372-0028 J AB Screw,ø3×20mm
707 92L394-0028 J AB Leg,Cushion
SP1 VSP0010PBS96A J AW Speaker,Woofer
ACCESSORIES/PACKING PARTS
1 92L411-0072 J Polyethylene Bag,Speaker
2 92L412-0079 J AP Packing Add.,Top/Bottom
SPEAKER BOX PARTS
701 92L121-0086 J AN Net Frame Ass’y
[CD-C470H/470E]
701 92L121-0097 J Net Frame Ass’y [CD-C480H]
703 92L351-0146 J AB Label [CD-C470H/470E]
703 92L351-0168 J Label [CD-C480H]
704 92L372-0028 J AB Screw,ø3×20mm
705 92L291-0051 J AP Speaker Cord
707 92L314-0015 J AL Bottom Cabinet
SP1,2 VSP0010PBT03A J AQ Speaker,Woofer
ACCESSORIES/PACKING PARTS
1 92L411-0063 J AB Polyethylene Bag,Speaker
2 92L412-0079 J AP Packing Add.,Top/Bottom
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A1~3 92LPWB2515MAN1 J — Main/SRS/Headphones
(Combined Ass’y)
[For CD-C470E Only]
PWB-B1,2 92LPWB2515PWR1 J — Power/Power Amp.
(Combined Ass’y)
[For CD-C470E Only]
PWB-C1,2 92LPWB2515DPL1 J — Display/Switch (Combined Ass’y)
[For CD-C470E Only]
PWB-D 92LPWB2515TUN1 J — Tuner [For CD-C470E Only]
PWB-E QPWBF0027AWZZ J AD CD Motor (PWB Only)
[For CD-C470E Only]
PWB-F QPWBF0314AWZZ J AD Tape Mechanism (PWB Only)
[For CD-C470E Only]
PWB-G QPWBF0341AWZZ J AB Tray Motor (PWB Only)
[For CD-C470E Only]
PWB-H QPWBF0313AWZZ J AB Head (PWB Only)
[For CD-C470E Only]
SPEAKER BOX PARTS
701 92L200L0370010 J AT Front Panel,Left
701 92L200R0370010 J AT Front Panel,Right
702 92L10002470E10 J BC Cabinet Ass’y [CP-C470E]
702 92L10002470H10 J BC Cabinet Ass’y [CP-C470H]
702 92L10002480H10 J Cabinet Ass’y [CP-C480H]
703 92L20100330010 J AN Net Frame Ass’y
[CP-C470H/470E]
703 92L20100480H10 J AS Net Frame Ass’y [CP-C480H]
704 92L23056121000 J AD Holder,Catcher
705 92L3121C470H10 J Speaker Cord Ass’y
[CP-C470H/480H]
705 92L3121PC46010 J Speaker Cord Ass’y [CP-C470E]
706 92L411B840160P J AD Screw,ø4×16mm
707 92L44010212400 J AC Port Cushion
708 92L411B930100P J AC Screw,ø3×10mm
709 92L6000C470E00 J AD Label,Specifications [CP-C470E]
709 92L6000C470H00 J Label,Specifications [CP-C470H]
709 92L6000C480H00 J AD Label,Specifications [CP-C480H]
710 92L44210310100 J AD Wire Cushion
C1,2 92L3582710L100 J 2.7µF,100V,Electrolytic,
Non-Polar
SP1,2 92L30012002800 J AY Speaker,Woofer
SP3,4 92L30205004000 J AQ Speaker,Tweeter
SP5,6 92L303R0300100 J Speaker,Super Tweeter
ACCESSORIES/PACKING PARTS
1 92L70032000910 J AE Polyethylene Bag,Speaker
2 92L71525001900 J AG Sheet,Speaker
3 92L74031000600 J AE Shield Pad,Speaker [CP-C470E]
3 92L74031000700 J AE Shield Pad,Speaker
[CP-C470H/480H]
4 92L720PC330000 J AM Packing Add.,Top/Bottom
5 92L6100C470H0 J Label,Feature
– 10 –
CP-C470H/CP-C470E/CP-C480H
CENTER SPEAKER SYSTEM
SURROUND SPEAKER SYSTEM
