GB-10
Use when the unit operates with the cool, dry, fan or ventilation mode. During operation,
Plasmacluster ions are always released into the room.
• The exhaust hose must be installed in these modes.
• Ensure that the stopcock is securely attached the drainpipe.
USE FOR AIR CONDITIONER
DRY MODE
1
Press the MODE button to select DRY mode.
COOL DRY FAN VENT
2
Press the A/C button to start operation.
• The green AIR CON lamp will light.
• The temperature cannot be set.
• The fan speed is preset to AUTO and cannot be
changed.
TO TURN OFF
Press the OFF button.
• The green AIR CON lamp will turn off.
NOTES:
• Although you can also operate dry mode without the exhaust hose, the unit generates heat during
operation and the room temperature will rise.
• It is also possible to operate in dry mode with hose (not included) attached.
Remove the stopcock and attach the hose to the drainpipe and lead to a oor drain to allow water to
drain from the unit.
2
1
COOL MODE
1
Press the MODE button to select COOL mode.
COOL DRY FAN VENT
2
Press the A/C button to start operation.
• The green AIR CON lamp will light.
TO TURN OFF
Press the OFF button.
• The green AIR CON lamp will turn off.
3
Press the TEMP button to set temperature.
• The temperature setting range: 18°C to 32°C.
4
Press the FAN button to set fan speed.
AUTO SOFT LOW HIGH
2
3
1
4
01_CV-P10PR_OM_EN.indd 10 14/08/29 16:42

Sharp CV-P10PR Specifications

General

Type	Monobloc mobile air conditioner
Hose length	1.5 m
Noise level	52 dB
Hose diameter	140 mm
Ionic function	Yes
Number of speeds	3
Airflow (high speed)	34.8 m³/h
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1 l/h
Timer duration (maximum)	12 h
Air conditioner functions	Cooling, Dehumidifying, Ventilating
Cooling capacity in watts (max)	2500 W
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	-
Connected load	960 W
AC input voltage	220-240 V
AC input frequency	50 Hz
Annual energy consumption (cooling)	- kWh
Product color	Silver

Weight and Dimensions

Depth	450 mm
Width	500 mm
Height	830 mm
Weight	42000 g
