Sharp LC-26AF3 M/H/X User Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
130
LC-26AF3 M/H/X
LC-32AF3 M/H/X
LC-37AF3 M/H/X
SUPPLIED ACCESSORIES
LC-26AF3M/H/X
S1 SPAKCC120WJZZ – Packing Case(LC-26AF3H) —
S1 SPAKCC121WJZZ – Packing Case(LC-26AF3M) —
LC-26AF3M/H/X
X1 QACCBA046WJPZ J AC Cord(LC-26AF3H)
X1 QACCKA013WJPZ J AC Cord(LC-26AF3M) AN
X1 QACCLA027WJPZ J AC Cord(LC-26AF3X) AS
X2 RRMCGA405WJSA J Remote Control Unit AS
(LC-26AF3M/X)
X2 RRMCGA406WJSA J Remote Control Unit
(LC-26AF3H)
X3 TiNS-B889WJZZ J Operation Manual
(LC-26AF3M)
X3 TiNS-B890WJZZ J Operation Manual
(LC-26AF3H)
X3 TiNS-B891WJZZ J Operation Manual AL
(LC-26AF3X)
X4 TCAUZA159WJZZ J Caution Card(LC-26AF3X) AD
X5 LHLDW0110CEZZ J Cable Clamp AE
X6 LHLDZ2013CEZZ J Cable Band AD
X7 XBBS940P14000 J Screw,x1 (TENTOU-BOUSI) AB
LC-32AF3M/H/X
X1 QACCKA013WJPZ J AC Cord(LC-32AF3M) AN
X1 QACCLA027WJPZ J AC Cord(LC-32AF3X)
X1 QACCBA046WJPZ J AC Cord(LC-32AF3H)
X2 RRMCGA405WJSA J Remote Control Unit AS
(LC-32AF3M)
X2 RRMCGA406WJSA J Remote Control Unit
(LC-32AF3H/X)
X3 LHLDW0110CEZZ J Cable Clamp AE
X4 LHLDW1164CEZZ J Clamp, x2 AA
X5 LHLDZ2013CEZZ J Cable Band AD
X6 TiNS-B889WJZZ J Operation Manual
(LC-32AF3M)
X6 TiNS-B890WJZZ J Operation Manual
(LC-32AF3H)
X6 TiNS-B891WJZZ J Operation Manual
(LC-32AF3X)
X7 TCAUZA159WJZZ J Caution Card(LC-32AF3X)
X8 XBBS940P14000 J Screw,x1 (TENTOU-BOUSI) AB
X9 XTBS940P16000 J Screw,x2 (TENTOU-CLAMP)AB
LC-37AF3M/H/X
X1 QACCKA013WJPZ J AC Cord (LC-37AF3M) AN
X1 QACCBA046WJPZ J AC Cord (LC-37AF3H)
X1 QACCLA027WJPZ J AC Cord (LC-37AF3X)
X2 RRMCGA405WJSA J Remote Control Unit AS
(LC-37AF3M/X)
X2 RRMCGA406WJSA J Remote Control Unit
(LC-37AF3H)
X3 LHLDW0110CEZZ J Cable Clamp AE
X4 LHLDW1164CEZZ J Clamp, x2 AA
X5 LHLDZ2013CEZZ J Cable Band AD
X6 TiNS-B889WJZZ J Operation Manua
(LC-37AF3M)
X6 TiNS-B890WJZZ J Operation Manual
(LC-37AF3H)
X6 TiNS-B891WJZZ J Operation Manual
(LC-37AF3X)
X7 TCAUZA159WJZZ J Caution Card(LC-37AF3X)
X8 XBBS940P14000 J Screw,x1 (TENTOU-BOUSI) AB
X9 XTBS940P16000 J Screw,x2 (TENTOU-CLAMP)AB
SERVICE JIGS
QCNW-C222WJQZ J 80pins FFC L=1000mm, AW
Main to LCD Panel x2
Used(SC4651/SC4652)
QCNW-C656WJQZ J 16pins L=1000mm, AV to
Power Unit (PA)
QCNW-C657WJQZ J 24pins L=1000mm, Main to
Power Unit (PB)
QCNW-C658WJQZ J 5pins L=1000mm, Main to
Power Unit (PC)
QCNW-C659WJQZ J 2pins L=1000mm, Power to
Inverter Unit (PD)
QCNW-C661WJQZ J 6pins L=1000mm, Power to
Inverter Unit (PF)
QCNW-C662WJQZ J 1pins L=1000mm, Power to
Inverter Unit (GV)
PALJiGUiF-001 J Interface Jig Software
upgrading tool
PACKING PARTS
(NOT REPLACEMENT ITEM)
S1 SPAKCC122WJZZ – Packing Case(LC-26AF3X) —
S2 SPAKFA902WJZZ – Accessories Case —
S3 SPAKFA827WJZZ – Stand Pad —
S4 SPAKPA558WJZZ – Wrapping Paper —
S6 SPAKXA826WJZZ – Packing Add. (Top) —
S7 SPAKXA827WJZZ – Packing Add. (Bottom) —
S8 SPAKXA828WJZZ – Packing Add. (Stand) —
S9 SSAKA0170CEZZ – Polyethylene Bag —
S10 SSAKA0219CEZZ – Polyethylene Bag —
S11 TLABK0001TAZZ – NO. Card, x2 —
S12 TLABNB411WJZZ – NO. Label —
S13 TLABNB409WJZZ J Label(LC-26AF3H)
S13 TLABNB410WJZZ J Label(LC-26AF3X)
S13 TLABNB411WJZZ J Label(LC-26AF3M)
LC-32AF3M/H/X
S1 SPAKCC123WJZZ – Packing Case(LC-32AF3H) —
S1 SPAKCC124WJZZ – Packing Case(LC-32AF3M) —
S1 SPAKCC125WJZZ – Packing Case(LC-32AF3X) —
S2 SPAKFA863WJZZ – Accessories Case —
S3 SPAKFA897WJZZ – Stand Pad —
S4 SPAKPA382WJZZ – Wrapping Paper —
S5 SPAKPA487WJZZ – Wrapping Paper (Stand) —
S6 SPAKXA829WJZZ – Packing Add. (Top) —
S7 SPAKXA830WJZZ – Packing Add. (Bottom) —
S8 SPAKXA831WJZZ – Packing Add. (Stand) —
S9 SSAKA0170CEZZ – Polyethylene Bag —
S10 SSAKA0219CEZZ – Polyethylene Bag —
S11 TLABNB403WJZZ – NO. Label(LC-32AF3H) —
S11 TLABNB404WJZZ – NO. Label(LC-32AF3X) —
S11 TLABNB405WJZZ – NO. Label(LC-32AF3M) —
S12 TLABK0001TAZZ – NO. Card, x2 —
LC-37AF3M/H/X
S1 SPAKCC126WJZZ – Packing Case (LC-37AF3H) —
S1 SPAKCC127WJZZ – Packing Case (LC-37AF3M) —
S1 SPAKCC128WJZZ – Packing Case (LC-37AF3X) —
S2 SPAKFA863WJZZ – Accessories Case —
S3 SPAKFA865WJZZ – Stand Pad —
S4 SPAKPA338WJZZ – Wrapping Paper —
S5 SPAKPA487WJZZ – Wrapping Paper (Stand) —
S6 SPAKXA832WJZZ – Packing Add. (Top) —
S7 SPAKXA834WJZZ – Packing Add. (Bottom) —
S8 SPAKXA835WJZZ – Packing Add. Stand) —
S9 SSAKA0170CEZZ – Polyethylene Bag —
S10 SSAKA0219CEZZ – Polyethylene Bag —
S11 TLABNB406WJZZ – NO. Label (LC-37AF3H) —
S11 TLABNB407WJZZ – NO. Label (LC-37AF3X) —
S11 TLABNB408WJZZ – NO. Label (LC-37AF3M) —
S12 TLABK0001TAZZ – NO. Card, x2 —
