LC-26AF3 M/H/X
LC-32AF3 M/H/X
LC-37AF3 M/H/X
25
7 [RGB]
1 RGB ADJ
2R GAIN
3G GAIN
4B GAIN
5R OFFSET
6G OFFSET
7B OFFSET
8 [TUNER]
1 TUNER TEST
9 [M GAMMA INFO]
1 MGAMMA IN 1 W/B adjustment
2 MGAMMA IN 2
3 MGAMMA IN 3
4 MGAMMA IN 4
5 MGAMMA IN 5
6 MGAMMA IN 6
7 MGAMMA IN WRITE EEP writing of adjustment values
8 MGAMMA IN RESET Initialization of adjustment values
10 [M GAMMA 1-3]
1 MGAMMA R 1
2 MGAMMA G 1
3 MGAMMA B 1
4 MGAMMA R 2
5 MGAMMA G 2
6 MGAMMA B 2
7 MGAMMA R 3
8 MGAMMA G 3
9 MGAMMA B 3
10 MGAMMA WRITE EEP writing of adjustment values
11 [M GAMMA 4-6]
1 MGAMMA R 4
2 MGAMMA G 4
3 MGAMMA B 4
4 MGAMMA R 5
5 MGAMMA G 5
6 MGAMMA B 5
7 MGAMMA R 6
8 MGAMMA G 6
9 MGAMMA B 6 EEP writing of adjustment values
10 MGAMMA WRITE
12 [ETC]
1 EEP SAVE Saving adjustment values Writing adjustment values in the storage area
2 EEP RESTORE Restoring adjustment values Writing back stored adjustment values
3 STANDBY CAUSE RESET
4 AUTO INSTALLATION SW
5 SYS MODEL COUNTRY Selecting region Displaying selected regions
6. Special features
`
STANDBY CAUSE (Page 1/12)
To indicate the reason code when the unit last enters standby.
When the unit enters standby, the cause of the error is recorded on EEPROM as much as possible.
When repairing a defective unit, checking adjustment values may useful for detecting abnormalities.
`
EEP SAVE (Page 12/12)
Storage of EEP adjustment value
`
EEP RECOVER (Page 16/16)
Retrieval of EEP adjustment value from storage area
