LC-19S7E-BK LC-26S7E-BK LC-32S7E-BK

120

CHAPTER 9. PARTS GUIDE

[1] SPARE PARTS LIST（LC-19S7E-BK）

Item Component number SHARP code Description Qty

1185 078G0030904 M 9JR7800000005 Speaker + wire assembly 8ohm 3w 100X30mm 1

8751 089G179E30H904 9JR8900000008 FFC CABLE 30P 280mm P1.0 117201-30466 1

1172 089G204A15NLS1 9JR8900000009 POWER CORD 1.5M PE8C5Z1B90A-04B 1

1177 092TB1JX1A3WGM 9JR9200000003 BATTERY FOR ALL EXPORT MODE LR03 2

8391 095G801411F906 9JR9500000045 HARNESS 7P+4P-4P+5P 270mm+160mm 75375-HF 1

1176 098GRABD1NESPJ 9JR9800000003 REMOTE CONTROL RC-GJ2100B-H FOR SHARP 1

98 0G1T1030 10 47 CR3 9JR0100000024 PAN HEAD WITH WASHER 5

99 0M1G 330 6 47 CR3 9JR0100000025 SCREW 42-D005390 2

96 0M1G1740 8 47 CR3 9JR0100000026 SCREW FOR GROUND 42-D000649 4

97 0M1T1430 8 47 CR3 9JR0100000027 Screw PHW M3-0.5x8 TPS Zi/BL 2

95 0Q1T 940 12 47 CR3 9JR0100000008 T4X12 SCREW 4

300 705GZ915020 9JR7050000045 MAIN FRAME ASSY 1

30 705GZ934125 9JR7050000046 BEZEL ASSY 1

40 705GZ934126 9JR7050000047 REAR COVER ASSY 1

50 705GZ934127 9JR7050000048 STAND ASSY 1

35 705GZ934128 9JR7050000049 KEY PAD ASSY 1

705GZ941051 9JR7050000050 DFU ASSY 1

705GZ941052 9JR7050000051 DFU ASSY 1

1050 750TVM185B1112N0SH 9JR7500000014 PANEL M185B1-L01 NB CMO 1

1053 CBPF93KBP5 9JR9900000023 MAIN PCB ASSY 1

1112 IRPF9PB2 9JR9900000024 IR PCB ASSY 1

1114 KEPF9PA6 9JR9900000025 KEY PCB ASSY 1

100 N02T6008 1 9JR0200000001 SCREW 2

94 P01T0006 1 9JR0100000028 SCREW (PH+W6#x15 HI-LO W=13) 4

501 P07T0062 1 9JR0700000002 SCREW (PH+W6#x15 HI-LO W=13) 1

304 P11G0023101 9JR1100000002 Wire Saddle Clip (CH-01U) 2

P15T0558101 9JR1500000019 BRACKET_SIDE_ATV 1

P16G0012 1 9JR1600000001 GASKET(25*16*8) 1

90 P34T0369PAA 1T0100 9JR3400000006 NECK 1

126 P40G 190843 2A 9JR4000000035 RATING LABEL 1

130 P40G000184311A 9JR4000000006 CARTON LABEL 1

P40G0002843 6A 9JR4000000037 LABEL-SIDE-ATV 1

127 P40TA00081328A 9JR4000000004 FAMILY SHEET- SERVICE 1

519 P40TD000813 9A 9JR4000000005 family sheet 1

520 P40TD00081311A 9JR4000000036 FAMILY SHEET 1

131 P40TN00084357A 9JR4000000022 ITALIAN CAUTION LABEL 1

451 P44G9020101 9JR4400000026 CUSHION_T 1

452 P44G9020201 9JR4400000027 CUSHION_B 1

521 P44G9020843 1A 9JR4400000028 CARTON 1

453 P45G 46026 9JR4500000010 PE BAG(560X450-0.72mm) 1

515 P45T 77001 9JR4500000004 LLDPE WRAP 2

300 P45T 77512001 9JR4500000005 INK CARTRIDGE-EP-T 1

103 P50T 53002 9JR5000000002 cable tie 1

102 P52T 58013 9JR5200000007 ACETATE TAPE 1

P85T0113101 9JR8500000004 SHIELDING_ATV 1

1054 PWTV9942LPR1 9JR9900000026 POWER PCB ASSY 1

1053 CBPF93KBP5 9JR9900000023 MAIN PCB ASSY

C1109 065T040247312K 3 9JR6500000125 CHIP CAP 47N 16V X7R 10% 1

C1111 065T040222031J Y 9JR6500000019 CAP CHIP 0402 22P 50V NPO +/-5% 1

C1112 065T040210412K Y 9JR6500000014 CAP CHIP 0402 100N 16V X7R +/-10% 1

C1113 065T040210412K Y 9JR6500000014 CAP CHIP 0402 100N 16V X7R +/-10% 1

C1114 065T040247312K 3 9JR6500000125 CHIP CAP 47N 16V X7R 10% 1

C1116 065T0805106A5K 3 9JR6500000148 CHIP 10uF 10V X5R 10% 1

C1121 065T0805106A5K 3 9JR6500000148 CHIP 10uF 10V X5R 10% 1

C1122 065T040210312K Y 9JR6500000011 CAP CHIP 0402 10N 16V X7R +/-10% 1

C1123 065T0805106A5K 3 9JR6500000148 CHIP 10uF 10V X5R 10% 1
