Sharp LC-40LE630E Service Manual

172
LC-32LE63x
LC-40LE63x
LC-46LE63x
12.22.3 LC-46LE632, LC-46LX632 Mechanical Parts Listing
LC-46LE632, LC-46LX632 CABINET AND MECHANICAL PART LISTING
PRICE
1 CCABAC769WJ01 KS-CAB-A LC46. P --
2 GCABAC769WJ1A FRONT CABINET P --
3 GCABBB983WJ1A REAR CABINET P --
4 313912139121 VESA BRACKET TOP P --
5 313912139121 VESA BRACKET BOTTOM P --
6 R1LK460D3LB33Y 46" LCD MODULE P --
7 TLABZC453WJZZ PANEL LABEL (Except Russian models) (DLAB-D934WE01) P --
8
313912139461
TERMINAL COVER SIDE
P
REF No. PARTS DESCRIPTION *
PRICE
CODE
8 313912139461 TERMINAL COVER SIDE P --
9 313912138942 TERMINAL COVER BOTTOM P --
10 313912139811 STAND BRACKET P --
11 313912139541 PANEL BRACKET TOP and SIDE P --
12 313912139471 PANEL BRACKET BOTTOM P --
13 313917105821 FFC FI-R 41P LVDS (313929712621) P --
14 313917105591 FFC FI-R 51P LVDS (313929712621) P --
15 RUNTKA868WJPZ2 CONTROL BUTTON UNIT P --
16 310431120071 WIRE
(
HL
)
P--
16
310431120071
WIRE
(HL)
P
17 313912326761 EMC FOAM 6,5x20 L100MM P --
18 313912326771 EMC FOAM 4x10 L10MM P --
19 313917105701 WIRE (VH) P --
20 313913401201 POWER SWITCH AND INLET HOLDER BRACKET P --
21 313913401211 BARRIER SHEET P --
22 242201501159 PIN PUSH (x2) P --
23 242226440085 SPEAKER TWEETERS 5W P --
24 242226440088 SPEAKER SUBWOOFER 15W P --
25
313913401061
CABLE TIE
P
25 313913401061 CABLE TIE P --
26 TLABNE414WJZZ MODEL LABEL (DLAB-E065WE01) P --
27 TLABZC993WJZZ POP LABEL P --
28 TLABZC929WJZZ CE ENERGY LABEL P --
29 242201500193 SADDLE WIRE NY66 NT 11.5 WIRE HOLDER P --
30 242201500764 SADDLE WIRE NY66 NT 11 WIRE HOLDER P --
31 310430040561 M4X6TORX20 + SERRATED WASHER (x8) P --
32 252220000092 SCREW PAN TORX ST ZN BK M3x6 (x37) P --
33 313912041192 SCREW FLANGE TORX 1.8 PLASTITE
(
x6
)
P--
33
313912041192
SCREW
FLANGE
TORX
1.8
PLASTITE
(x6)
P
34 252270098355 SCREW HOLE PLUG TAPPED (x4) (HOLE RIVET TAPPED 5.5X14.5) P --
35 CDAI-A795WJ01 KS-STAND P --
36 QACCKA047WJPZ AC CORD PE8C5Z1B90A-05B 2,5A 1,8M P --
37
TINS F125WJZZ
QUICK START GUIDE
P
REF No. PARTS DESCRIPTION *
ACCESSORIES PARTS LISTING
PRICE
CODE
37 TINS-F125WJZZ QUICK START GUIDE P --
38
908210090001
BATTERY R03-B500/01S P --
39
313913872431
SCREW for STAND P --
40
TINS-F203WJZZ
SAFETY SHEET P --
41
313912568771
TRACEABILITY LABEL P --
42
314302620392
O/M PE BAG P --
43 RRMCGA965WJSA REMOTE CONTROL LE63*E P --
44 RRMCGA968WJSA Optional 2nd. REMOTE CONTROL (Only for LX63*E series). P --
PACKING PARTS LISTING
45 SPAKCG387WJZZ Packing Case P --
46
313913622191
Packing Case Bottom P --
47 SPAKPB477WJZZ Packing bag. P --
48 SPAKXD415WJZZ Pack-AD (EPS) TOP P --
49 SPAKXD416WJZZ Pack-AD (EPS) BOTTOM P --
REF No. PARTS DESCRIPTION *
PA
C
KIN
G
PART
S
LI
S
TIN
G
PRICE
CODE
