76
6. UPGRADING INSTRUCTIONS
6.1 Introduce for MSD6488 chip
6.1.1 Type of MS6488 chip
Chip type Demod DDR Area Function
6488EVE DVBT/C 8Gbit EU/AU Hbbtv/ Browser/APP
6488MVE DVBT/C 8Gbit EU/AUB Hbbtv/Browser/APP, inset
MEMC
6.1.2 Hardware
Chip type MS6488
Chip MS6488EV/MS6488MV
External DDR 1GByte
Flash 512MByte
Tuner R842/RT710
APM 5707/5711
EXT demod 102KA/102KT
SD Cardexuan optional
WIFI 7603/8188/7632(support Bluetooth)
CI optional
Note:
Flash detail:
size brand ash type
512MB MXIC MX30LF4G18AC-TI
External DDR detail:
size brand ash type
1GB NANYA NT5CB128M16IP-EK
6.2 Chip alias
Chip CVTE Name MSTAR Name
6488EV Muji 6488
6488MV Manhattan 6488E
6.3 Upgrading Instruction
6.3.1 The rules of USB upgrade le name
Because the software is not compatible between the chip, so can't rise each other, we use soft-
ware name distinguish it.
6488EV: allupgrade_6488.bin
6488.U701 use 6488EV chip
6488MV: allupgrade_6488m.bin
6488.U801, 6488.U703, 6488.U731 use 6488MV chip
