Sharp LC-52LE640U User Manual

LC-52/60/70LE640U,C6400U (1st Edition)
iv
LC52LE640U
Service Manual
OUTLINE
MAJOR SERVICE PARTS
PWB Unit
NOTE: *1 Replace MAIN PWB Units (DKEYMF733FM**) in case of IC8401, IC3303 or IC8455 failure.
*2 Replace LCD CONTROL Units (DUNTKA975FM**) in case of IC5803 failure.
OTHER Unit
IC For Exclusive Use Of The Service
Service Jigs
Ref No. Parts No. Description
N DKEYMF733FM84 MAIN Unit (LC-52LE640U/C6400U)
N DKEYMF733FM83 MAIN Unit (LC-60LE640U/C6400U)
N DKEYMF733FM82 MAIN Unit (LC-70LE640U/C6400U)
N DUNTKG015FM01 R/C, OPC Unit
N DUNTKG014FM01 ICON Unit
N DUNTKF800FM53 KEY Unit
N RUNTKA936WJQZ Wi-Fi Unit
N RUNTKA931WJQZ POWER/DRIVE Unit (LC-52LE640U/C6400U)
N RUNTKA932WJQZ POWER/DRIVE Unit (LC-60LE640U/C6400U)
N RUNTKA933WJQZ POWER/DRIVE Unit (LC-70LE640U/C6400U)
N DUNTKF975FM03 LCD CONTROL Unit (LC-52LE640U/C6400U)
N DUNTKF975FM02 LCD CONTROL Unit (LC-60LE640U/C6400U)
N DUNTKF975FM01 LCD CONTROL Unit (LC-70LE640U/C6400U)
Ref No. Parts No. Description
N R1LK520D3GV00Z 52" LCD Panel Module Unit (LK520D3GV00Z)
N R1LK600D3GV00Z 60" LCD Panel Module Unit (LK600D3GV00Z)
N R1LK695D3GW80Z 70" LCD Panel Module Unit (LK695D3GW80Z)
Ref No. Parts No. Description Q'ty
IC2001 RH-iXD241WJNSQ IC R5F21368CNFP (Monitor Microcomputer) 1
Ref No. Parts No. Description Q'ty
N QCNW-C222WJQZ Connecting Cord L=1000mm 80pins, LCD Control Unit to LCD Panel Unit 2
N QCNW-M580WJQZ Connecting Cord L=1000mm 41pins, Main to LCD Control Unit (LW) 1
N QCNW-L795WJQZ Connecting Cord L=1000mm 24pins, Main to POWER Unit (PD) 1
N QCNW-L807WJQZ Connecting Cord L=1000mm 4pins, Power to LCD Control Unit (PL) 1

Sharp LC-52LE640U Specifications

General

Display diagonal	52 \
Display brightness	- cd/m²
Native aspect ratio	16:9
Native refresh rate	120 Hz
Supported video modes	1080p
Viewing angle, vertical	176 °
Contrast ratio (dynamic)	4000000:1
Supported graphics resolutions	1920 x 1080 (HD 1080)
3D	No
Placement supported	Horizontal
Product color	Black
Panel mounting interface	- mm
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
HDCP	-
HDMI version	1.4
HDMI ports quantity	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	0
Component video (YPbPr/YCbCr) in	1
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	- W
Power consumption (typical)	150 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	333 mm
Height (with stand)	771 mm
Weight (with stand)	25500 g
Depth (without stand)	72 mm
Width (without stand)	1208 mm
Height (without stand)	739 mm
Weight (without stand)	22500 g
