Sharp R-15AT Service Manual

34
R-15AT
PARTS LIST
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
*
*
∆
*
*
*
ELECTRIC PARTS
AM RMOTDA234WRE0 Antenna motor 1 AR
C RC-QZA320WRZZ High voltage capacitor 1 AV
F1 QFS-CA026WRZZ Fuse F10A 1 AH
F2 QFS-IA002WRE0 High voltage fuse 0.75 A 1 AQ
FM RMOTEA378WRE0 Fan motor 1 AU
MG RV-MZA299WRE0 Magnetron 1 BK
OL RLMPTA078WRE0 Oven lamp 1 AL
OL RLMPTA069WRE0 Oven lamp (Interchangeable) 1 AK
SW1 QSW-MA085WRE0 Primary interlock relay control switch 1 AF
SW2 QSW-MA085WRE0 2nd. interlock switch 1 AF
SW3 QSW-MA086WRE0 Monitor switch 1 AF
T RTRN-A717WRZZ High voltage transformer 1 BP
TC1 RTHM-A123WRZZ Thermal cut-out 125 deg. (OVEN) 1 AK
TC1 RTHM-A096WRE0 Thermal cut-out 125 deg. (OVEN) (Interchangeable) 1 AK
TC2 RTHM-A120WRE0 Thermal cut-out 145 deg. (MAG) 1 AH
TC2 RTHM-A080WRE0 Thermal cut-out 145 deg. (MAG) (Interchangeable) 1 AP
1- 1 QACC-A148WRZZ Power supply cord 1 AW
1- 2 FH-DZA091WRK0 High voltage rectifier assembly 1 AY
1- 3 FPWBFA367WRKZ Noise filter 1 AZ
1- 4 QSOCLA024WRE0 Oven lamp socket 1 AH
CABINET PARTS
2- 1 GCABUA672WRP0 Outer case cabinet 1 BH
2- 2 GDAI-A318WRW0 Base plate 1 AV
2- 3 GCOVHA406WRW0 Base plate cover 1 AQ
2- 4 GLEGPA074WRE0 Foot 2 AC
2- 5 GLEGPA076WRF0 Leg 1 AF
CONTROL PANEL PARTS
3- 1 DPWBFB911WRU0 Control unit 1 BP
3- 1A QCNCMA234DRE0 3-pin connector (CN-A) 1 AC
3- 1B QCNCMA275DRE0 2-pin connector (CN-B) 1 AB
3- 1C QCNCWA057DRE0 12-pin connector (CN-G) 1 AF
C1 VCEAB51EW228M Capacitor 2200 uF 25V 1 AE
C2 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C3 VCEAB31AW476M Capacitor 47 uF 10V 1 AA
C4 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C5 VCEAB31AW476M Capacitor 47 uF 10V 1 AA
C6 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C7 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C8-9 RC-KZA087DRE0 Capacitor 0.1 uF 50V 2 AA
C10 VCEAB31EW477M Capacitor 470 uF 25V 1 AC
C11 VCEAB31HW477M Capacitor 470 uF 50V 1 AE
C13 VCEAB31EW106M Capacitor 10 uF 25V 1 AA
C20 VCEAB31HW104M Capacitor 0.1 uF 50V 1 AM
C21 VCEAB31EW106M Capacitor 10 uF 25V 1 AA
C30 VCEAB31AW476M Capacitor 47 uF 10V 1 AA
C31 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C70 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
CF1 RCRS-A012DRE0 Ceramic resonator CST4.00MGW 1 AD
D1-6 RH-DZA006PRE0 Diode (1N4002) 6 AD
D20-21 VHD1SS270A/-1 Diode (1SS270A) 2 AA
D23 VHD1SS270A/-1 Diode (1SS270A) 1 AA
D70 VHD1SS270A/-1 Diode (1SS270A) 1 AA
IC1 RH-IZA897DRE0 LSI 1 AV
IC2 RH-IZA980DRE0 IC (AT24C02) 1 AD
IC3 RIC--A025BDE0 IC (KID65004AP) 1 AE
LED1 VHPSL3966T/1B Light emitting diode 1 AS
Q1 RIC--A022BDE0 IC (KIA7805P1) 1 AE
Q2 VSDTA123ES/-3 Transistor (DTA123ES) 1 AA
Q3 VSDTC143ES/-3 Transistor (DTC143ES) 1 AB
Q3 VSKRC101M//-3 Transistor (KRC101M) (Interchangeable) 1 AB
Q20 VSDTB143ES/-3 Transistor (DTB143ES) 1 AC
Q20 VSKRA223M//-3 Transistor (KRA223M) (Interchangeable) 1 AB
Q21 VSDTC143ES/-3 Transistor (DTC143ES) 1 AB
Q21 VSKRC101M//-3 Transistor (KRC101M) (Interchangeable) 1 AB
Q22 VSDTD143ES/-3 Transistor (DTD143ES) 1 AC
Q22 VSKRC243M//-3 Transistor (KRC243M) (Interchangeable) 1 AB
Q24 VS2SC1740S/-3 Transistor (2SC1740) 1 AB
R3-5 VRD-B12EF472J Resistor 4.7k ohm 1/4W 3 AA
R6 VRD-B12EF102J Resistor 1k ohm 1/4W 1 AA
R30 VRD-B12EF101J Resistor 100 ohm 1/4W 1 AA
R31 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA

Sharp R-15AT Specifications

General

Grill	No
Rotisserie	-
Control type	Buttons
Display type	LCD
Product type	Solo microwave
Certification	CE
Product color	Stainless steel
Microwave power	1000 W
Built-in display	Yes
Appliance placement	Countertop
Number of power levels	11
Current	16 A
Connected load	- W
AC input voltage	230 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	424 mm
Width	520 mm
Height	309 mm
Weight	18000 g
Interior dimensions (W x D x H)	351 x 372 x 211 mm
