19
The wires in the mains cable are colour coded as shown
opposite:
As the colours of the cores in the mains lead of your oven
may not correspond with the coloured marking identifying the
terminals in your plug, connect the wires as shown: Make sure
the terminal screws are tight and the cable is held securely by
the cable grip where it enters the plug. Like most appliances
in your home, your oven must be connected to a single phase
230-240 Volt, 50 Hz alternating current supply.
If you do not make the proper electrical connections you might
damage the oven or injure yourself. Neither SHARP nor the
supplier will be liable if this happens.
TO REPLACE THE MAINS PLUG
green and yellow stripes = EARTH
blue = NEUTRAL
brown = LIVE
• The green and yellow wire to the plug terminal marked E or
or coloured green or coloured green and yellow.
• The blue wire to the plug terminal marked N or coloured
black or coloured blue.
• The brown wire to the plug terminal marked L or coloured
red or coloured brown.
!
WARNING
THIS APPLIANCE MUST BE EARTHED.
IF YOU HAVE ANY DOUBTS ABOUT YOUR ELECTRICAL
SUPPLY ASK A QUALIFIED ELECTRICIAN.
• If you are unable to resolve a problem using the checks
covered on the last few pages, do not attempt to service this
microwave oven yourself.
• Contact the dealer or supplier from whom the oven was
purchased in order to obtain service.
01296 663400 (office hours)
CALLING FOR SERVICE
• For general information & assistance with oven queries,
please contact our help desk:
Telephone: 01296 663400 (office hours)
e-mail: customerservice@rhhall.com
R-7500M[EN].inddSec3:19 2019/02/0117:24:02

Sharp R-7500M Specifications

Power

AC line voltage	230-240 V
AC power required	2.85 kW
output power	1800 W

Frequency and Sound

microwave frequency	2450 MHz
sound level	less than 70 dB

Capacity

oven capacity	0.7 cu.ft (19 litres)
cooking uniformity	Rotary antenna system

Weight and Dimensions

outside dimensions (single)	420(W) x 337(H) x 480(D) mm
outside dimensions (two ovens stacked)	420(W) x 674(H) x 480(D) mm
cavity dimensions	332(W) x 171.5(H) x 330(D) mm
weight	Approx. 20 kg
