7. PARAMETER SETTING VM-5S
-42-
7-5-4 DISPLAY CONTENT
The characters and numerals indicated on the LCD display when setting the parameters represent
the following parameters and their status.
MEAS 1····Displays the parameters that can be set.
Display Parameter
SPEED RELAY 2 set (over speed)
SPEED RELAY 4 set (over speed)
SPEED RELAY 1 set (over speed)
SPEED RELAY 3 set (over speed)
SPEED RELAY 2 set (under speed)
SPEED RELAY 4 set (under speed)
SPEED RELAY 1 set (under speed)
SPEED RELAY 3 set (under speed)
CH1 trigger level set
CH2 trigger level set
CH1 measured value span adjustment
CH2 measured value span adjustment
CH1 recorder output zero adjustment
CH2 recorder output zero adjustment
CH1 recorder output span adjustment
CH2 recorder output span adjustment
LCD display
MEAS2
MEAS1
4
8
12
16
0
0
20 20
40 40
60 60
80 80
100
%
100
%
%
%
MEAS 1
20
V
MEAS1 MEAS2
