Siemens A50 User Manual

16
8/13/02 k45dm-ger.fm A50 Stingray, en, A31008-H5110-A1-1-7619
Making a phone call
Call menu
The following functions are only
available during a call:
;
menu§ Open menu.
Microphone
on
Switch the microphone on or
off. If switched off, the person
on the other end of the line
cannot hear you (muting).
Alternatively:
*
Hold down.
However, numbers being en-
tered are audible when Send
DTMF tones is active.
Volume Adjust handset volume.
Conference (p. 15).
Duration/
charges
While the connection contin-
ues, the call duration and
(if set, see p. 47) the charge
details are displayed.
Send DTMF
tones
See right.
Call transfer
~
(p. 15).
Main menu Direct access to the main
menu.
Call status List all held and active calls
(e.g. participants in a
conference).
Send DTMF tones
;
menu§ Open menu.
Send DTMF tones
Select.
You can enter control codes (digits)
during a call so that an answering
machine can be controlled remotely.
These digits are directly transmitted
as DTMF tones (control codes).
Control codes (DTMF tones) stored
in the Phonebook (p. 18) can also be
entered.

Siemens A50 Specifications

General

Display resolution	101 x 64 pixels
Networking type	GSM
Operating frequency	900, 1800 MHz
Display number of lines	5 lines
Internal memory	0 MB
WAP	1.2.1
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Ringer type	Monophonic
Microphone included	Yes
Form factor	Bar
Phonebook capacity	50 entries
Text prediction system type	T9
Personal info management (PIM)	Alarm clock, Calculator
Talk time (2G)	5 h
Battery capacity	600 mAh
Standby time (2G)	250 h
Product color	Blue

Weight and Dimensions

Depth	23 mm
Width	46 mm
Height	109 mm
Weight	95 g
