44
Info level
To enter the Info level, proceed as follows:
1 in any menu position, press keys + and - at the same time, then the program will start again: the display will show OFF.
2 , until the display will show InFo, Press the enter (InFo) key
3 then il will show the first code (167) flashing, on the right side it will show the data entered. By pressing + or - it is possible to scroll
(up or down) the parameter list.
4 If a dot-line is shown on the right, there is no enough room for complete visualisation: press enter again the data will be completely
shown for 1 to 3 seconds. By pressing enter or + and- at the same time, the system will exit the parameter visualisation and go
back to the flashing number.The Info level shows some basic parameters as:
5 Example: choose parameter 102 to show the date
the display shows parameter 102 flashing on the left and characters ._._ on the right.
6 press InFo for 1-3 seconds: the date will appear
7 press InFo to go back to parameter “102”
8 by pressing + / -, it is possible to scroll up/down the parameter list (see table above), or, by pressing ESC or InFo for more seconds,
the display will show
9 Once the last parameter is accessed (143) by pressing + , the End message will flash.
Parameter Description
167 Cubic meters of fule (resettable)
162 Operating hours (resettable)
163 Device operating hours
164 Burners start-ups (resettable)
166 Total number of start-ups
113 Burner number (i.e. serial number)
107 Software version
102 Software date
103 Device serial number
104 Customer code
105 Version
143 Free
