CPU 31xC and CPU 31x, Technical Data
Manual, 01/2006 Edition, A5E00105475-06
7-1
Technical data of CPU 31x
7
7.1
7.1
General technical data
7.1.1
Dimensions of CPU 31x
Each CPU features the same heigh
t and depth, only the width dim
ensions differ.
•
Height: 125 mm
•
Depth: 115 mm, or 180 mm with opened front cove
r.
Figure 7-1
Dimensio
ns of CPU 31x
166
168
