4.3 Analyzer Functions
LDS 6
52 Operating Instructions, 01/2009, A5E00295894-05
4.3.4 Measuring Ranges
Table 4- 5
41 Define Ranges
3
41 Define Ranges Ch1 NH 3
0.000 100.0 mg/Nm
Start Value End Value
You can use this function to define a measuring range by assigning a start-of-scale value to the
bottom value (4 mA) and a full-scale to the top value (20 mA) of the analog output.
4.3.5 Parameters
Table 4- 6
Parameters Ch1 NH 3
...Continue
53 Status Messages
52 Transmission
51 Limits
50 Response Time
This display, showing the selection of the parameter functions 50 to 53 appears following the
selection of the parameter functions in the main menu by pressing the fourth soft key
("Parameters"). You can branch to the parameter functions 54 to 60 by pressing the fifth soft key
(...Continue).
50 Response Time
Value: 63.28 mg/Nm
50 Response Time Ch1 NH
3
3
Actual Measured
[5.000] Seconds
You can use this function to set various time constants to reduce or suppress noise in the
measured signal.
