104/301
Siemens Building Technologies Basic Documentation LMV5... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 13.08.2004
Example: Calling up and selecting submenu «Burner control»
B u r n e r C o n t r o l
R a t i o C o n t r o l
L o a d C o n t r o l l e r
A Z L
Example: Calling up and selecting submenu «Times»
T i m e s
C o n f i g u r a t i o n
V a l v e P r o v i n g
F l a m e F a i l T e s t
Example: Calling up and selecting submenu «Times Startup»
T i m e S t a r t u p 1
T i m e S t a r t u p 2
T i m e S h u t d o w n
T i m e G e n e r a l
Example: Calling up and selecting parameter «Prepurge Time Gas»
M i n T i m e S t a r t R e l
F a n R u n u p T i m e
P r e - p u r g e T i m e G a s
P r e - p u r g e T i m e O i l
Setting the parameter:
a) After the required parameter has been called up and selected, the display shown be-
low will appear. Lines «Curr» and «New» show identical values at first, namely the
actual parameter value.
The pointer automatically points to the colon
on line «New». Here, the required new
value can be entered,
whereby the AZL5… automatically displays the 4 possible line setting ranges with the
associated resolutions:
- 0...12.6 s resolution 0.2 s
- 13...63 s resolution 1 s
- 70...630 s resolution 10 s
- 11...63 min resolution 1 min
P r e - p u r g e T i m e G a s
C u r r : 1 2 . 6 s
N e w : 1 2 . 6 s
First submenu level
Second submenu level
Third submenu level
Fourth submenu level
