Sequence steps of adaption (self-setting):
1) Starting the adaption
Using the AZL5… menu, the heating engineer manually activates the adaption function
of the LC.
After selecting menu item «Adaption» (within the parameter settings of the LC), the fol-
lowing display will appear:
− The pointer is positioned on «Start adaption». Adaption is activated by pressing En-
ter
S t a r t A d a p t i o n
w i t h E N T E R 6 0
S e t p o i n t : 7 0 . 0 ° C
A c t V a l : 6 0 . 0 ° C
Adaption starts after pressing
Enter whereupon the following text appears:
A d a p t a c t i v e
L o a d : 5 2 . 0 %
A c t V a l : 6 0 . 0 ° C
C a n c e l w i t h E S C
Depending on the adaption step, the following displays appear, alternating with the dis-
play shown above:
A d a p t a c t i v e
S e t t i n g P h a s e
m a x . 1 0 m i n
C a n c e l w i t h E S C
A d a p t a c t i v e
T e m p S e t b a c k
A c t V a l : 6 0 . 0 ° C
C a n c e l w i t h E S C
A d a p t a c t i v e
H e a t i n g
m a x . 1 0 m i n
C a n c e l w i t h E S C
Special function
adaption LC
