PARAMETER LISTING.....................................................
Parameter Function Range Default Unit
*P000 Operating display 0-8 0 (output
frequency)
Hz
P001 Display mode 0-8 0
*P002 Ramp-up time 0-150.0 20 sec
*P003 Ramp-down time 0-150.0 20 sec
P005 Digital frequency setpoint 0-150.0 50.00 (60,00 =
North America)
Hz
*P006 Frequency setpoint source selection 0-2 0 -
*P007 Keypad control 0 or 1 1 -
P010 Display scaling 0.01-500.0 1.00 -
*P012 Minimum motor frequency 0-150.0 0,0 Hz
*P013 Maximum motor frequency 0-150.0 50.00 (60,00 =
North America)
Hz
P014 Skip frequency 1 0-150.0 0.0 Hz
P015 Automatic re-start after mains break 0-1 1
*P016 Start on the fly 0 or 2 0 V
P018 Automatic re-start after fault 0-1 0
P019 Skip frequency bandwidth 0.0-10.0 2.0 Hz
P021 Minimum analog frequency 0-150.0 0.0 Hz
P022 Maximum analog frequency 0-150.0 50.00 (60,00 =
North America)
Hz
P023 Analog input 1 type 0-2 0
P025 Analog output 1, 0-105 0
P026 Analog output 2 (MIDIMASTER Eco only) 0-105 2
P027 Skip frequency 2 0-150.0 0.0 Hz
P028 Skip frequency 3 0-150.0 0.0 Hz
P029 Skip frequency 4 0-150.0 0.0 Hz
P041 Fixed frequency 1 0-150.0 5.0 Hz
P042 Fixed frequency 2 0-150.0 10.00 Hz
P043 Fixed frequency 3 0-150.0 15.00 Hz
P044 Fixed frequency 4 0-150.0 20.00 Hz
P046 Fixed frequency 5 0-150.0 25.00 Hz
P047 Fixed frequency 6 0-150.0 30.00 Hz
P051 Selection control function, DIN1 (terminal 5), fixed
frequency 5
024 1
P052 Selection control function, DIN2 (terminal 6), fixed
frequency 4
024 10
P053 Selection control function, DIN3 (terminal 7), fixed
frequency 3
024 6
P054 Selection control function, DIN4 (terminal 8), fixed
frequency 2
024 6
P055 Selection control function, DIN5 (terminal 16), fixed
frequency 1
024 6
P061 Selection relay output RL1 0-13 6
P062 Selection relay output RL2 0-13 1
P065 Current threshold for relay 0.0-300.0 1.0 A
P066 Compound braking 0-250 0
P073 DC injection braking 0-200 0 range is variant
dependent
%
P074 1
2
t motor de-rating 0-7 1
P076 Pulse frequency 0-7 0
P077 Energy saving mode or multi-motor mode selection 0-4 4
P079 Starting boost 0-250 50
P080 Nominal rating plate motor power factor (cosϕ) 0.00-1.00 
*P081 Motor rating plate nominal frequency 0-150.00 50.00 (60,00 =
North America)
Hz
*P082 Motor rating plate nominal speed 0-9999  RPM
*P083 Motor rating plate nominal current 0.1-590  A
*P084 Motor rating plate nominal voltage 0-1000  V
* Indicates Basic Parameters
 Value depends on rating of the inverter
