2.3 Product design
The following is the mechanical design of the Climatix capacitive touch panel,
POL8T2.40.
No. Description No. Description
1 Display / touch screen 6 RS485 communication port
2 LED indicators 7 DIP switches
3
Recesses for a mounting
clip
8 Label
4 USB-A port 9 Power supply connection
5 USB-B port
