Siemens RDG100KN User Manual

2 / 14
Siemens RDG100KN Room thermostat with KNX communications CE1N3191en
Building Technologies 01 Jun 2010
Use
The RDG100KN room thermostat is designed for use with the following types of
system:
Fan coil units via ON/OFF or modulating control outputs:
 2-pipe system
 2-pipe system with electric heater
 2-pipe system and radiator / floor heating
 4-pipe system
 4-pipe system with electric heater
 2-stage heating or cooling system
Chilled / heated ceilings (or radiators) via ON/OFF or modulating control
outputs:
 Chilled / heated ceiling
 Chilled / heated ceiling with electric heater
 Chilled / heated ceiling and radiator / floor heating
 Chilled / heated ceiling, 2-stage cooling or heating
The room thermostats are delivered with a fixed set of applications.
The relevant application is selected and activated during commissioning using one
of the following tools:
 Synco ACS
 ETS3 Professional (planned)
 Local DIP switch and HMI
Functions
 Room temperature control via built-in temperature sensor or external room
temperature / return air temperature sensor
 Changeover between heating and cooling mode (automatic via local sensor or
bus, or manual)
 Selection of applications via DIP switches or commissioning tool (ACS700,
ETS3 Professional)
 Select operating mode via operating mode button on the thermostat
 Temporary Comfort mode extension
 Single speed or 3-speed fan control (automatic or manual)
 Display of current room temperature or setpoint in °C and/or °F
 Minimum and maximum limitation of room temperature setpoint
 Button lock (automatic or manual)
 3 multifunctional inputs, freely selectable for:
 Operating mode switchover contact (keycard, window contact, etc.)
 Sensor for automatic heating / cooling changeover
 External room temperature or return air temperature sensor
 Dewpoint sensor
 Electric heater enable
 Fault input
 Monitor input for temperature sensor or switch status
 Advanced fan control function, e.g. fan kick, fan start, selectable fan operation
(enable, disable or depending on heating or cooling mode)
 Purge function together with 2-port valve in a 2-pipe changeover system
 Reminder to clean fan filters
 Floor heating temperature limitation
 Reload factory settings for commissioning and control parameters

Siemens RDG100KN Specifications

General

Brand	Siemens
Model	RDG100KN
Category	Thermostat
Language	English
