Siemens RDG100KN Room thermostat with KNX communications CE1N3191en
Building Technologies 01 Jun 2010
Accessories
Description
Product no. /
stock no.
Data
sheet
Changeover mounting kit (50 pcs / package)
ARG86.3
N3009
Adapter plate 120 x 120 mm for 4“ x 4“
conduit boxes
ARG70
N3009
Adapter plate 112 x 130 mm for surface wiring
ARG70.2
N3009
KNX Power supply 160 mA (Siemens BT LV)
5WG1 125-1AB01
--
KNX Power supply 320 mA (Siemens BT LV)
5WG1 125-1AB11
--
KNX Power supply 640 mA (Siemens BT LV)
5WG1 125-1AB21
--
Mechanical design
The room thermostat consists of 2 parts:
 Plastic housing with electronics, operating elements and room temperature
sensor
 Mounting plate with the screw terminals
The housing engages in the mounting plate and is secured with 2 screws.
1) Operating mode button / Esc
2) Fan mode button / Ok
3) Rotary knob to adjust setpoints and
parameters
Operation and settings
2
1
3
