SCALANCE XR-300WG
Operating Instructions, 05/2017, C79000-G8976-C454-01
59
Dimension drawings
8
Note
Dimens
ions are specified in mm.
Front view of the SCALANCE XR-300WG
Figure 8-1 Width and height
SCALANCE XR-300WG 24 VDC variant view from above
Figure 8-2 Depth
SCALANCE XR-300WG 240 VAC variant view from above
Figure 8-3 Depth
