Siemens SED2-3/32B User Manual

15/126
Siemens Building Technologies SED2 variable speed drives CM1U5192en
HVAC Products Mechanical installation 01.2002
3.3.1.2 Dimensions of SED2 footprint filters for frame sizes A to C
Dimensions in mm
Frame size
ABCGH I JK
A
200 73 43.5 60 160 56 187 22
B
213 149 50.5 138 174 120 200 24
C
245 185 55 174 204 156 232 35
B
I
K
A
J
H
G
C
5192J03
I
K
A
J
H
C
5192J04
B
G
Filter for frame size A Filter for frame sizes B and C
3.3.1.3 Dimensions of SED2 frame sizes D to F
Dimensions in mm
Frame size
ABC
D
520 275 245
E
650 275 245
F
850
(with filter
1150)
350 320
5
1
9
2
J
0
5
A
B
C
