12.3 System interfaces
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
243
12.3.4 System interfaces on the operator panel and the operator panel with display
Versions and safety notices
The operator panel has two system interfaces:
● Rear side system interface. This is not normally accessible on an integrated operator
panel. The incoming cable from the basic unit or expansion module is always connected
here.
● Front system interface. This is normally accessible on an integrated operator panel.
Components are only connected directly when needed, and removed again after use.
These can be:
– Memory module
– Addressing plug
– PC cable for connecting a PC / PG
– Cover (if the system interface is not in use).
Connect the system interfaces only when they are fully de-energized!
System interface on the operator panels (degree of protection IP54):
To ensure degree of protection IP 54
• press the cover into the socket as far as it will go when it is used for the first time!
• When fastening the operator panel with the screws supplied, do not apply an excessive
tightening torque.
