Overview of functions
5.3 Safety-oriented tripping
SIMOCODE pro
52 System Manual, 05/2019, A5E40507475002A/RS-AD/004
5.3 Safety-oriented tripping
The SIMOCODE pro motor management system has two modules for the safety-related
tripping of motors:
● Fail-safe digital module DM-F local: For applications requiring safety-related tripping of a
motor feeder via a hardware signal that is acquired and evaluated by the module.
● DM-F PROFIsafe fail-safe digital module: For applications that require the safety-related
tripping of a motor feeder by a fail-safe controller (F-CPU) via the communication bus with
the fail-safe PROFIsafe profile.
These modules conform to the general requirements for EMERGENCY STOP devices or
safety circuits described in EN 418 and EN 60204-1 (06.2006).
Depending on the external circuit, the following Performance Level / Safety Integrity Level
can be achieved:
● PL e with Category 4 according to ISO 13849-1 or
● SIL 3 according to IEC 61508/62061
Safety technology and safety-related functions
● Are exclusively restricted to the fail-safe digital modules.
● Do not directly affect existing SIMOCODE pro components and concepts.
A more detailed description is provided in the documentation listed below
● Manual Fail-safe Digital Modules SIMOCODE pro, German
(https://support.automation.siemens.com/WW/view/de/50564852
)
● Manual Fail-safe Digital Modules SIMOCODE pro, English
(https://support.automation.siemens.com/WW/view/de/50564852/0/en
)
● Manual Fail-safe Digital Modules SIMOCODE pro, French
(https://support.automation.siemens.com/WW/view/de/50564852/0/fr
)
● Manual Fail-safe Digital Modules SIMOCODE pro, Spanish
(https://support.automation.siemens.com/WW/view/de/50564852/0/es
)
● Operating instructions "Fail-Safe Digital Module DM-F Local"
(https://support.automation.siemens.com/WW/view/en/49222263
)
● Operating instructions "Fail-Safe Digital Module DM-F PROFIsafe"
(https://support.automation.siemens.com/WW/view/en/49222281
).
You will find the System Manuals and Operating Instructions at Manuals/operating
instructions (https://support.industry.siemens.com/cs/ww/en/ps/16027/man
)
CAUTION
Loss of safety function is possible
For the 24 V DC power supply, always use an SELV or PELV power supply unit!
For capacitive and inductive loads, an adequate protective circuit is required!
