Technical data
15.6 Technical data of the expansion modules
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
351
15.6.4 Technical data of the DM-F-PROFIsafe digital module
Technical data of the DM-F PROFIsafe digital module
LED display DM-
F PROFIsafe
"READY"
System interface not connected / supply voltage too low / device defective
Device ON/system interface OK
Device ON / system interface not active or not OK
"DEVICE"
Device defective or faulty
"OUT"
Safety-related output not active
Safety-related output active
Feedback circuit not closed although start condition satisfied
"GF"
Red
Group fault (PROFIsafe not active, incorrect PROFIsafe address, wiring
"7"
Yellow PROFIsafe address 64
"8"
Yellow PROFIsafe address 128
"9"
Yellow PROFIsafe address 256
for setting the PROFIsafe address
• Displays the set PROFIsafe address
• Application of the set PROFIsafe address (restart of the module)
• Resetting of faults (also possible via "TEST/RESET" button on basic unit)
• 3 inputs (83, 85, 89) 24 V DC
• Supply via terminal 84 or external supply
(static +24 V)
• Common connected, electrically isolated inputs for acquiring process signals (e.g., local
control station, keyswitch, limit switch, etc.), freely assignable to control functions
Input with safety relay
function
• 1 feedback circuit input (91/FBC) 24 V DC
• For contactor monitoring of the motor and incoming supply contactors via series-connected
auxiliary switch contacts
• Supply via terminal 90/T
300 m
Type 2 according to EN 61131-2
