Technical data
15.6 Technical data of the expansion modules
SIMOCODE pro
356 System Manual, 05/2019, A5E40507475002A/RS-AD/004
1) Technical data residual current transformer 3UL23: See Manual 3UG4/3RR2 Monitoring
Relay (https://support.industry.siemens.com/cs/ww/en/view/54397927
).
15.6.9 Technical data of the temperature module
Technical data of the temperature module
Mounting
Snap-mounted onto 35-mm standard mounting rail or
screw-mounted using additional push-in lugs
Display
• Green "READY" LED • Continuous light: "Ready for operation"
• Flashing: "No connection to basic unit"
System interface
For connecting to a basic unit, an additional expansion
module, a current measuring module or a current / voltage
measuring module or the operator panel.
Sensor circuit
Conversion time
500 ms
Type of connection
2-wire or 3-wire connection
Typical sensor current:
• PT100
1 mA (typical)
• PT1000 / KTY83 / KTY84 / NTC
0.2 mA (typical)
Open circuit detection / short-circuit detection / measuring
range:
• PT100 / PT1000
Open circuit, short-circuit; measuring range:
-50 °C to +500 °C
• KTY83-110
Open circuit, short-circuit; measuring range:
-50 °C to +175 °C
• KTY84
Open circuit, short-circuit; measuring range:
-40 °C to +300 °C
• NTC
Short-circuit; measuring range: +80 °C to +160 °C
Measuring accuracy at an ambient temperature of 20 °C
(T20)
< ±2 K, ±1 digit
Deviation due to ambient temperature
(as % of measured value)
0.05 per K deviation from T20
Isolation of the inputs from the device electronics
No
Connection
Tightening torque TORQUE: 7 LB.IN - 10.3 LB.IN 0.8 Nm - 1.2 Nm
Connection cross sections
• Solid:
2x 0.5 mm
2
to 2.5 mm
2
/ 1x 0.5 mm
2
to 4 mm
2
2x AWG 20 to 14 / 1x AWG 20 to 12
• Finely stranded with end sleeve:
2x 0.5 mm
2
to 1.5 mm
2
/ 1x 0.5 mm
2
to 2.5 mm
2
2x AWG 20 to 16 / 1x AWG 20 to 14
