Description 02.00
3-8 Siemens AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
3.4.3 Converters 3AC 400V, 210A to 600A, 1Q
Order No. 6RA70 . . – 6DS22
75 78 81 85
Rated supply voltage armature
1)
V 3AC 400 (+15% / – 20%)
Rated input current armature
2)
A 175 233 332 498
Rated supply voltage electronics
power supply
V 2AC 380 (– 25%) to 460 (+15%); I
n
=1A oder
1AC 190 (– 25%) to 230 (+15%); I
n
=2A
(– 35% for 1min)
Rated supply voltage fan V DC 24V internal 3AC 400 (±15%) 50Hz
3AC 460 (±10%) 60Hz
Fan rated current A 0,24
Air flow rate m
3
/h 100 570
Fan noise level dBA 40 73
Rated supply voltage field
1)
V 2AC 400 (+15% / – 20%)
7)
Rated frequency Hz 45 to 65
Rated DC voltage
1)
V 485
Rated DC current A 210 280 400 600
Overload capability
6)
max. 180% of rated DC current
Rated output kW 102 136 194 291
Power loss at rated DC current
(approx.)
W 676 800 1328 1798
Rated DC voltage field
1)
V max. 325
Rated DC current field A 15 25
Operational ambient temperature °C 0 to 40 at I
rated
3)
forced-cooled
Storage and transport
temperature
°C – 25 to +70
Installation altitude above sea level
≤ 1000 m at rated DC current
4)
Control stability Q 
0.006% of the rated motor speed, valid for pulse encoder operation and
digital setpoint
Q 
0.1% of the rated motor speed, valid for analog tacho or analog
setpoint
5)
Environmental class DIN IEC 721-3-3 3K3
Degree of protect. DIN 40050
IEC 144
IP00
Dimensions (HxWxD) mm 385x265x283 625x268x318
Weights (approx.) kg 16 17 30
Explanation at end of list of tables
