Environmental Conditions
Temperatures
Type test, in operation
(in compliance with IEC 60068-2-1 and
IEC 60068-2-2, test Ad for 16 h and test Bd for 16 h)
-25 °C to +85 °C
Temporarily permissible during operation (tested for
96 h)
-25 °C to +70 °C
Load conditions for the non-modular devices: With
temperatures above 55 °C, no more than 50 % of the
binary inputs and relay outputs per printed circuit
board assembly are allowed to be continuously active.
Readability of the display may be impaired below
-10 °C and above +55 °C.
Recommended for uninterrupted duty
(in compliance with IEC 60255-1)
-10 °C to +55 °C
Temperatures for continuous storage -25 °C to +55 °C
Type test, transport and storage for 16 h -40 °C to +85 °C
Heat-related limitations for the binary inputs on the IO216 input module (modular devices)
Switching thresholds Up to 55 °C Up to 70 °C
220 V operating voltage All 16 binary inputs usable for uninter-
rupted duty
10 binary inputs usable for uninter-
rupted duty
Heat-related limitations for the binary inputs on the IO230 input module (modular devices)
Switching thresholds Up to 40 °C Up to 55 °C Up to 70 °C
Range 1 for 24 V, 48 V,
and 60 V operating
voltage
All 48 binary inputs usable
for uninterrupted duty
All 48 binary inputs usable
for uninterrupted duty
All 48 binary inputs usable
for uninterrupted duty
Range 2 for 110 V and
125 V operating voltage
All 48 binary inputs usable
for uninterrupted duty
All 48 binary inputs usable
for uninterrupted duty
36 binary inputs usable
for uninterrupted duty
(max. 3 in each group of 4
at the same time)
Range 3 for 220 V and
250 V operating voltage
36 binary inputs usable
for uninterrupted duty
(max. 3 in each group of 4
at the same time)
24 binary inputs usable
for uninterrupted duty
(max. 2 in each group of 4
at the same time)
12 binary inputs usable
for uninterrupted duty
(max. 1 in each group of 4
at the same time)
NOTE
At an ambient temperature of 55 °C to 70 °C, a maximum of 36 relays per row can be switched on simulta-
neously.
Heat-related limitations for the binary inputs on the IO231 input module (modular devices)
Switching thresholds Up to 40 °C Up to 55 °C Up to 70 °C
Range 1 for 24 V, 48 V,
and 60 V operating
voltage
All 24 binary inputs usable
for uninterrupted duty
All 24 binary inputs usable
for uninterrupted duty
All 24 binary inputs usable
for uninterrupted duty
Range 2 for 110 V and
125 V operating voltage
All 24 binary inputs usable
for uninterrupted duty
All 24 binary inputs usable
for uninterrupted duty
18 binary inputs usable
for uninterrupted duty
(max. 3 in each group of 4
at the same time)
6.9
Technical Data
6.9 Environmental Conditions
224 SIPROTEC 5, Hardware Description, Manual
C53000-G5040-C002-F, Edition 06.2019
