Siemens SIPROTEC 5 Hardware Description Manual

Design Data
Masses
Device Size
Weight of the Modular Devices
Type of construction 1/3 1/2 2/3 5/6 1/1
Flush-mounting device 4.4 kg 7.2 kg 9.9 kg 12.7 kg 15.5 kg
Surface-mounted device with inte-
grated on-site operation panel
7.4 kg 11.7 kg 15.9 kg 20.2 kg 24.5 kg
Surface-mounted device with
detached on-site operation panel
4.7 kg 7.8 kg 10.8 kg 13.9 kg 17.0 kg
Size Weight
Detached on-site operation panel 1/3 1.9 kg
Detached on-site operation panel 1/6 1.1 kg
Device Size
Weight of the Non-Modular Devices 7xx81, 7xx82
Type of construction 1/3
Flush-mounting device 3.6 kg
Bracket for non-modular surface-
mounted variant
1.9 kg
Dimensions of the Base and 1/3 Modules
Type of Construction (Maximum Dimensions)
Width over all x Height over all x Depth (incl.
Current Terminal), Width and Depth Each Rounded
up to the Next Full mm (in Inches)
Flush-mounting device 150 mm x 266 mm x 229 mm
(5.91 x 10.47 x 9.02)
Surface-mounted device with integrated on-site oper-
ation panel
150 mm x 314 mm x 337 mm
(5.91 x 12.36 x 13.27)
Surface-mounted device with detached on-site opera-
tion panel
150 mm x 314 mm x 230 mm
(5.91 x 12.36 x 9.06)
Dimensions of the Device Rows
Type of
Construction
(Maximum
Dimensions)
Width over all x Height over all x Depth (incl. Current Terminal), Width and Depth
Each Rounded up to the Next Full mm (in Inches)
Type of construc-
tion
1/3 1/2 2/3 5/6 1/1
Flush-mounting
device
150 mm x
266 mm x
229 mm
(5.91 x 10.47 x
9.02)
225 mm x
266 mm x
229 mm
(8.86 x 10.47 x
9.02)
300 mm x
266 mm x
229 mm
(11.81 x 10.47 x
9.02)
375 mm x
266 mm x
229 mm
(14.76 x 10.47 x
9.02)
450 mm x
266 mm x
229 mm
(17.72 x 10.47 x
9.02)
Surface-
mounted device
with integrated
on-site operation
panel
150 mm x
314 mm x
337 mm
(5.91 x 12.36 x
13.27)
225 mm x
314 mm x
337 mm
(8.86 x 12.36 x
13.27)
300 mm x
314 mm x
337 mm
(11.81 x 12.36 x
13.27)
375 mm x
314 mm x
337 mm
(14.76 x 12.36 x
13.27)
450 mm x
314 mm x
337 mm
(17.72 x 12.36 x
13.27)
6.13
Technical Data
6.13 Design Data
SIPROTEC 5, Hardware Description, Manual 229
C53000-G5040-C002-F, Edition 06.2019
