Silvercrest SKR 800 A1 User Manual

8 SKR 800 A1
GB
IE
■ Do not place the device in a hot, wet or extremely damp environment or in the vicinity
of flammable materials.
■ The mounting location must be selected so that the device is not exposed to steam.
Do not install the device directly over a hotplate.
■ The mains power socket must be easily accessible so that the power cable can be
easily disconnected in an emergency.
Installation under a wall cupboard
3,1 cm
6,3 cm
You can install the device under a wall cupboard using the supplied mounting plate
4
.
Proceed as follows to mount the device:
♦ Slide the mounting plate to the rear and remove it from the device.
♦ Find a suitable installation location for the device (see also the section Set-up
location requirements).
♦ Hold the mounting plate under the installation location. Ensure that the front edge
of the mounting plate is approx. 3.1cm behind the front of the cupboard so that the
device is flush with the cupboard after installation. The side edges of the mounting
plate must be around 6.3cm from any adjacent cabinets or walls.
♦ Mark the 4 mounting points with a pencil.
♦ Using a spike or nail, make a small depression at the respective marking points.
♦ If required, place the supplied spacers
14
between the cupboard and the mounting
plate. If using the spacers, you will need the long mounting screws
15
.
♦ Screw the mounting plate tight using the mounting screws (
15
or
16
) provided.
♦ Push the device with its top against the mounting plate
4
until it clicks audibly into
place.
♦ Check to ensure that the device is securely seated.
