Silvercrest SWE 100 A1 User Manual

Multi-Band Tuner SWE 100 A1
English - 13
Technical Specifications
Operating voltage 3 V
Power adapter plug
polarity
Max. current consumption 100 mA
Battery Type 2x AA 1.5 V (LR6)
Output power 100 mW
Frequency bands
Please note that the given
tuning bands may slightly vary
upwards or downwards
because of product
tolerances.
FM 87,5 - 108 MHz
MW 530 - 1660 kHz
SW1 5,9 - 6,2 MHz
SW2 9,4 - 9,9 MHz
SW3 11,6 - 12,1 MHz
SW4 13,57 - 13,87 MHz
SW5 15,1 - 15,8 MHz
SW6 17,48 - 17,9 MHz
Dimensions 132 x 78 x 30 mm (W x H x D)
Weight 146 g (without batteries)
Headphones SWE 100 A1
Impedance 32 Ohms
Wide Band Characteristic
Voltage approx. 120 mV
Max. sound pressure level
with supplied headphones approx. 92 dB(A)
Max. output voltage on
headphones jack approx. 70 mV
Operating temperature 5 °C to 35 °C
Operating humidity 85 % rel. humidity

Silvercrest SWE 100 A1 Specifications

General

Brand	Silvercrest
Model	SWE 100 A1
Category	Radio
Language	English
