Specifications
NOTE: Specifications are correct at time of printing and are subject to change without notice.
ENGINE
17 HP Briggs & Stratton Intek
Make Briggs & Stratton
Model Intek
Horsepower 17 @ 3600 rpm
Cylinder 1
Bore 3.57 in (91 mm)
Stroke 3.06 in (78 mm)
Displacement 30.6 Cu. in (500 cc)
Construction Overhead Valve, Cast-Iron Sleeve,
Aluminum Crankcase
Electrical System 12 Volt, 3 amp. Alternator Unregulated
Battery: 200 Cold Cranking amps,
23 Min. Reserve Capacity
Ignition High Energy Electronic Ignition
Air Cleaner Ducted Paper Cartridge & Foam Pre-cleaner
Lubrication Splash Lubrication
Oil Capacity 56 Oz. (1.7 L)
Muffler Compact, Low Back Pressure
15.5 HP Briggs & Stratton Intek
Make Briggs & Stratton
Model Intek
Horsepower 15.5 @ 3600 rpm
Cylinder 1
Bore 3.44 in (88 mm)
Stroke 3.06 in (76.5 mm)
Displacement 28.4 Cu. in (465 cc)
Construction Overhead Valve, Cast-Iron Sleeve,
Aluminum Crankcase
Electrical System 12 Volt, 3 amp. Alternator Unregulated
Battery: 200 Cold Cranking amps,
23 Min. Reserve Capacity
Ignition High Energy Electronic Ignition
Air Cleaner Ducted Paper Cartridge & Foam Pre-cleaner
Lubrication Splash Lubrication
Oil Capacity 48 Oz. (1.42 L)
Muffler Compact, Low Back Pressure
14.5 HP Briggs & Stratton Intek
Make Briggs & Stratton
Model Intek
Horsepower 14.5 @ 3600 rpm
Cylinder 1
Bore 3.44 in (88 mm)
Stroke 3.06 in (76.5 mm)
Displacement 28.4 Cu. in (465 cc)
Construction Overhead Valve, Cast Iron Sleeve,
Aluminum Crankcase
Electrical System 12 Volt, 3 amp Alternator Unregulated
Battery: 200 Cold Cranking amps,
23 Minute Reserve Capacity
Ignition High Energy Electronic Ignition
Air Cleaner Ducted Paper Cartridge & Foam Pre-cleaner
Lubrication Splash Lubrication
Oil Capacity 48 Oz. (1.42 L)
Muffler Compact, Low Back Pressure
TRANSMISSION
Hydro Models
Type Hydrostatic Tuff Torq K51
Pump Variable Displacement Axial Piston
Motor Fixed Displacement Axial Piston
Control Single Lever Hand Control
Movement Free-Wheeling Lever for Manual Tractor
Hydraulic Fluid 10w 30 Premium Engine Oil
Speeds Forward: 0-5.2 MPH (8.3 km/h)
@ 3400 rpm Reverse: 0-3 MPH (4.8 km/h)
Differential Bevel Gear Type
Axle Shaft .75 in
Continuous Torque 170 ft. lbs.
Output
Drawbar Rating 243 lbs.
Maximum Weight 673 lbs.
on Axle
Gear Models
Type Peerless MST 205
Material Shaft: Hardened
Bearings: Needle Roller & Bushings
Lubrication EP 90 Oil
Speeds Five Forward, One Reverse
Speeds 1st: 1.0 MPH (1.6 km/h)
@ 3400 rpm 2nd: 2.0 MPH (3.2 km/h)
3rd: 3.0 MPH (4.8 km/h)
4th: 4.2 MPH (6.7 km/h)
5th: 4.7 MPH (7.5 km/h)
Rev: 1.4 MPH (2.2 km/h)
Differential Bevel Gear Type
Axle Shaft .75 in
Continuous Torque 225 ft. lbs.
Output
Drawbar Rating 321 lbs.
Maximum Weight 525 lbs.
on Axle
CHASSIS
All Models
Frame Heavy Gauge Steel Channel - 12/14 Gauge
Engine Mounting: Above Front Axle
Pivot Point Location: Rear Carrier
Rear Wheels Tire Size: 18 x 8.50-8 Turf Type
Pneumatic Inflation Pressure:
10-12 psi (.8-1 bar)
Front Wheels Tire Size: 15 x 6.00-6
Pneumatic Inflation Press.:
12-15 psi (.8-1 bar)
Bearings: Sintered Iron with Grease Fittings
Accessibility Hood Tips Forward, Seat Tips Forward
Fuel Tank Material: High Density Polyethylene,
Transparent
Capacity: 2.0 Gallons (7.5 L)
Seat Medium Back, Adjustable
Turning Radius Inside Rear Tire: 14 in (36 cm)
