38
Specifications
COMMON REPLACEMENT PARTS
Use only genuine factory replacement parts. Do not attempt
repairs or maintenance unless proper procedures and safety pre-
cautions are followed. For assistance see your dealer.
QTY. DESCRIPTION PART NO.
1 Tractor Drive Belt-Hydro Models 1717397
1 Tractor Drive Belt-Gear Models 1665450
1 38” (97 cm) Mower Drive Belt 1716854
1 38” (97 cm) Mower Blade - RH 1704101
1 38” (97 cm) Mower Blade - LH 1704856
1 44”(112 cm) Mower Drive Belt 1719911
3 44” (112cm) Mower Blade 1704100
1 Fuel Filter 173206
1 Exhaust Screen 1719961
1 Battery 1685215
1 Ignition Key 1717163
2 Headlight Bulb 1677371
1 Interlock Switch - PTO 1717050
1 Interlock Switch - Neutral (Hydo Models) 1665586
1 Interlock Switch - Neutral (Gear Models) 1654634
1 Interlock Switch - Seat 1714711
Interlock Switch - Foot pedals
1 - Switch, Black (normally open) 1704379
1 - Switch, Gray (normally closed) 1714770
Dozer/Snow Blade
Rear Wheel Weights
Tire Chains
Twin Bag Grass Catcher
Grass Mulcher/Leaf Shredder
Front Counterweight
Dump Cart
Gas Cans
OPTIONAL ACCESSORIES
MAINTENANCE ITEMS
DESCRIPTION PART NO.
Engine Oil
SAE 5W-30 SF/CD (Cold Weather 30° & under) 1685576
SAE 30W SG/CC (Warm weather 32° & up) 1685659
Touch-Up Paint
Metallic Grey, 13 oz. spray can 1685718
Cardinal Red, 13 oz. spray can 1686772
Cardinal Red, Case of 12 spray cans 1686774
Cardinal Red, 1 quart can 1686773
Solar Black, 13 oz. spray can 1686779
Solar Black, 1 quart can 1686781
Grease Gun Kit w/8 oz. Grease Tube 1685510
Replacement 8 oz. Grease Tube for above 103077
Tire Sealant 11 oz. Tube 1685523
Degrimer/Degreaser
32 oz. Bottle w/Trigger Spray 1685619
1 gallon 1685621
Gas Stabilizer
8 oz. Bottle 1685748
Case of 12 - 8 oz. Bottles 1685747
Dielectric Silicone Compound 1685799
CONTROLS
All Models
Steering 15" (38 cm) Steering Wheel
Gear and Sector, 1.5 turns Lock to Lock
Clutch/ Brake Combination Clutch/Brake/Parking Brake
Pedal. Parking Brake Lock,
Foot/Hand Activated
Location Mower Height Adjustment: Right Side
PTO Clutch-Manual, Dash
Ground Speed Lever-Seat Deck R.H.
Ignition Key Switch: On Seat Deck
Throttle Lever & Choke Lever:
(Combined) On Dash Panel
DIMENSIONS
Tractor
Overall Length 68 in (172 cm)
Overall Width 36 in (92 cm)
Height At Steering Wheel: 41 in (104 cm)
To Top of Engine Cover: 34 in (86 cm)
Wheel Base 50 in (127 cm)
Weight (approx.)
Net 371 lbs. (168 kg) w/mower 455 lbs. (206 kg)
Shipping 610 lbs. (276 kg) w/38 in Mower
Tractor Length
w/Dozer Blade est. 86 in (218 cm)
38” (97 cm) Mower
Material 12 Ga.
Effective Cutting 38 in (97 cm)
Width
Overall Width 49.5 in (126 cm)
with Deflector
Weight 81 lbs. (36.7 kg)
Cutting Height Variable Between 1.5 and 3.9 in
(3.8 and 10 cm)
Blade Arrangement Two Blades
Mower Drive V-Belt from Tractor Engine Pulley
Spindle Bearings Sealed Ball Bearings - Lube Fitting Provided
44” (112 cm) Mower
Material 12 Ga.
Effective Cutting 44 in (97 cm)
Width
Overall Width 56 in (142 cm)
with Deflector
Weight 107 lbs. (49 kg)
Cutting Height Variable Between 1.5 and 3.9 in
(3.8 and 10 cm)
Blade Arrangement Three Blades
Mower Drive V-Belt from Tractor Engine Pulley
Spindle Bearings Sealed Ball Bearings - Lube Fitting Provided
