Sinee A90-4T060 User Manual

User Manual of A90 Series Inverter
294
parameter in
running
cannot be written. If necessary, please shut down the inverter.
08H
Parameter
protection by
password
The current register is protected by a password.
12.4 Protocol Description
12.4.1 Definition of inter-frame and intra-frame time interval
A complete MODBUS message contains not only the necessary data units, but also the
starting and ending tags. Thus, as shown in Fig. 0-1 or Fig. 0-3, the idle level with a
transmission time of 3.5 characters or more is defined as the starting and ending tag. If
there is an idle level with a transmission time of more than 1.5 characters during message
transmission, the transmission will be deemed exceptional.
Specific starting/ending and exception intervals are related to the baud rate, as detailed
in Table 0-5. If the baud rate is 9,600bps and the sampling period is 1ms, the starting and
ending time interval is the idle level of 4ms or more (3.5×10/9600=3.64≈4), and the
exceptional data interval is the idle level in which the interval of data bits of one frame is
greater than or equal to 2ms (1.5×10/9600=1.56≈2) and less than 4m (the idle level of
normal data bits is less than or equal to 1ms).
Table 0-5 Correspondence between Time Interval and Baud Rate (t
adjust
=1ms)
Baud Rate
(bps)
Starting and
ending time
interval
T
interval
(t
adjust
)
Exception
interval
T
exception
(t
adjust
)
Remarks
4800
8
4
The idle level of 3ms or less is allowed for a
normal frame. When the idle level is 8ms or
greater, it indicates the end of a frame of data.
9600
4
2
The idle level of 1ms or less is allowed for a
normal frame. When the idle level is 4ms or
greater, it indicates the end of a frame of data.
19200
2
1
The idle level of less than 1ms is allowed for a
normal frame. When the idle level is 2ms or
greater, it indicates the end of a frame of data.
Higher
1
1
When an idle level of 1ms appears, it indicates
the end of a frame.
