Singer 1408 User Manual

Winding the Bobbin
- Place the thread and Spool pin felt (a) onto the spool pin. (1)
- Wind thread clockwise around bobbin winder tension discs.
(2)
- Thread bobbin as illustrated and place on spindle. (3)
- Push bobbin spindle to right. (4)
- Hold thread end. (5)
- Step on foot control pedal. (6)
- Cut thread. (7)
- Push bobbin spindle to left (8) and remove.
When the bobbin winder spindle is in "bobbin winding"
position, the machine will not sew and the hand wheel will
not turn. To start sewing, push the bobbin winder spindle to
the left (sewing position).
Please Note:
EN
11

Singer 1408 Specifications

General

Free Arm	Yes
Built-in Needle Threader	No
Reverse Stitch	Yes
Type	Mechanical
Built-in Stitches	8
Stitch Width	5 mm
Presser Feet	All-purpose foot, zipper foot, buttonhole foot, button sewing foot
Buttonhole Type	4-Step
Bobbin Type	Front-loading
Included Accessories	Needles, bobbins, screwdriver, seam ripper, lint brush
Weight	7 kg
